2.2.2

Rack-Mounting the InfiniteStorage 6120 Chassis

The InfiniteStorage 6120 is designed to fit within a 4U rack space. Follow these steps to mount the
system in your rack:
Using eight (8) 10-32 × 0.188" Phillips panhead screws for each slider, attach the four (4) inner
1.
sliders to the chassis as shown in
2. For expansion enclosure, skip this step and proceed to the next step.
Loosen the nine (9) screws on the rail kit and set the length to fit the depth of your rack
(Figure 15)
other rail kit.
0 0 7 - 5 5 3 3 - 0 0 1
Figure 14
Figure 14. Attach 4 Inner Sliders to Chassis
. Tighten all the screws once the rail kit is set to the desired length. Repeat for the
Figure 15. Adjust Rail Kit Length
Loosen (9) Screws to
Adjust Rail Kit Length
Setting Up the InfiniteStorage 6120
below.
17
