3.4
Firmware Update Management
SGI periodically releases firmware updates to enhance features of the products. Please contact our
SGI Technical Support to obtain the latest firmware files.
3.4.1
Displaying Current Firmware Version
The SHOW CONTROLLER <id> ALL_ATTRIBUTES command displays version information of the
InfiniteStorage 6120's hardware and firmware
3.4.2
Firmware Update Procedure
The firmware update procedure described here only applies to upgrades from firmware
version 1.0.3.3.xxxx to a new version. Upgrades from an older version of firmware must be
done by a trained technician.
NOTE : Before you begin upgrading the firmware, make sure all access to the
InfiniteStorage 6120 is stopped, all volumes on the storage array are unmounted, and allow
sufficient time for the InfiniteStorage 6120 to flush all cached data.
!
Warning
0 0 7 - 5 5 3 3 - 0 0 1
Figure 74. Controller Information Screen
RAID$ show controller local all_attributes
OID:
0x38000001
Firmware Version:
Release:
1.0.3.3
Source Version:
1877
Fully Checked In:
Yes
Private Build:
Yes
Build Type:
Production
Build Date and Time:
2009-03-02-09:49:EST
Builder Username:
compiler
Builder Hostname:
ereo-debian
Build for CPU Type:
AMD-64-bit
Hardware Version:
0x0
State:
RUNNING
Local AP OID:
0x00000000
Memory Size:
0x0
Max Q of S ID:
0x0
Up Time (seconds):
0x7fe3
Last Event Sequence #:
0x27b
Log Facility Mask:
Crash Dump Enabled:
TRUE
Log Disk Enabled:
TRUE
RP Count:
0x1
Restart Pending:
FALSE
Name:
B
Controller:
LOCAL
Controller ID:
0x0015b2a1214a0000
MIR Reason:
None
Firmware update should only be performed when both controllers are
powered on and running.
Firmware Update Management
.
(Figure 74)
(SECONDARY)
52
