If there is a failed drive, SHOW UNASSIGNED_POOL FAILED ALL will display the failed drive's
information
Figure 51. Failed Drive Example Screen
3.2.1.2

Storage Pool View

Storage pools are the basic building blocks of the InfiniteStorage 6120.
SHOW POOL * displays the list of configured storage pools in the system
Figure 52. Storage Pool List Example Screen
SHOW POOL <id> PHYSICAL_DISK displays the list of disks associated with the specified storage
pool
(Figure 53)
Figure 53. Storage Pool's Physical Disks Example Screens
SHOW POOL <id> VIRTUAL_DISK displays the list of virtual disks associated with the specified
storage pool
Figure 54. Storage Pool's Virtual Disks Example Screens
SHOW POOL <id> ALL displays detailed information of the storage pool
0 0 7 - 5 5 3 3 - 0 0 1
.
(Figure 51)
RAID$ show unassigned_pool failed all
OID: 0x20a7003f
Pool OID: UNASSIGNED
Capacity: 704512 MBs (0x56000000 blocks)
Raw Capacity: 715404 MBs (0x575466f0 blocks)
Block Size: 512
Enabled Disk Ch: 0x27 0x22
Disk Slot: 1:42
Vendor ID: Hitachi
Product ID: Hitachi HUA721075KLA330
Product Revision: GK8OAB0A
Serial Number: GTF200P8GBVPXF
Health State: FAILED
Rotation Speed: 7200 RPM
Device Type: SATA
Member State: UNASSIGNED
Spare: FALSE
Failed: TRUE
UUID: 0x5000cca215c564560
RAID$ show pool *
OID: 0x19b40000 Index: 0x0000 Name: 19b40000
OID: 0x19b60001 Index: 0x0001 Name: 19b60001
.
RAID$ show pool 0 physical_disk
0x003e NORM 0x5000cca215c56e47
0x003f NORM 0x5000cca215c56456
0x0040 NORM 0x5000cca215c54c71
0x0041 NORM 0x5000cca215c5675c
0x0042 NORM 0x5000cca215c56e55
.
(Figure 54)
RAID$ show pool 0 virtual_disk
OID: 0x89ba0000 Index: 0x0000 Name: 89ba0000
OID: 0x89bb0001 Index: 0x0001 Name: 89bb0001
Configuration Management
.
(Figure 52)
.
(Figure 55)
