Figure 55. Storage Pool Details Example Screen
3.2.1.3
Virtual Disk View
SHOW VIRTUAL_DISK * displays the list of configured virtual disks in the system
Figure 56. Virtual Disk List Example Screen
SHOW VIRTUAL_DISK <id> ALL_ATTRIBUTES will display detailed information of the virtual disk
(Figure 57)
Figure 57. Virtual Disk Details Example Screen
0 0 7 - 5 5 3 3 - 0 0 1
RAID$ show pool 0 all_attributes
OID:
0x19b40000
Type:
STORAGE
Name:
0x19b40000
Chunk Size:
64KB (0x80 blocks)
Block Size:
0x200
RAID Type:
RAID5
Free Raid5 Capacity:
2801664 MBs
Max VD Size:
2801664 MBs
Total Capacity:
3522560 MBs
UUID:
0x00
Global Spare Pool:
UNASSIGNED
DiskTimeout(FRT):
10 minutes
Init Policy:
NO IO permitted
Init Priority:
50%
Full Rebuild Priority:
Fractional Rebuild Priority:
Sparing Policy:
AUTOMATIC
Assign Policy:
Device Type:
NA
Rotation Speed:
NA
Raw Capacity:
NA
SATAssure:
FALSE
IO ROUTING:
TRUE
WBC:
TRUE
MWBC:
FALSE
Initializing:
TRUE
Rebuilding:
FALSE
Paused:
FALSE
AutoWriteLock:
FALSE
Critical:
FALSE
Current Home:
0x0015b2a122b20000
Future Home:
0xffffffffffffffff
Preferred Home:
0x0015b2a122b20000
BkgdJob OID:
0x28000003
Total Phy Disks
5
State:
NORMAL
Member Size:
704512 MB
pID
State
UUID
0x003e
NORM
0x5000cca215c56e47
0x003f
NORM
0x5000cca215c56456
0x0040
NORM
0x5000cca215c54c71
0x0041
NORM
0x5000cca215c5675c
0x0042
NORM
0x5000cca215c56e55
RAID$ show virtual_disk *
OID: 0x89ba0000 Index: 0x0000 Name: 89ba0000
OID: 0x89ba0001 Index: 0x0004 Name: 89ba0001
.
RAID$ show virtual_disk 0 all_attributes
OID:
0x89ba0000
Name:
89ba0000
POOL OID:
0x19b40000
Capacity:
16384 MBs
Offset:
0x0
State:
NOT RDY
Raidlevel:
RAID5
IO ROUTING:
TRUE
WBC:
TRUE
MWBC:
FALSE
Initializing:
TRUE
Paused:
FALSE
AutoWriteLock:
FALSE
Data Lost:
FALSE
Present Home Only:FALSE
Current Home:
0x0015b2a122b20000
Future Home:
0xffffffffffffffff
Preferred Home:
0x0015b2a122b20000
BkgdJob OID:
0x28000000
UUID:
60001ff0722b20000000000089ba0000
80%
90%
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
Configuration Management
.
(Figure 56)
40
