2.3.5

Checking Status of Physical Disks

Before creating any storage pools, check the status of all the drives.
1. Enter command SHOW UNASSIGNED_POOL ALL_ATTRIBUTES
Figure 28. Show Unassigned Pool Example Screen
2. Verify that all the drives are present and healthy. If the drives are not visible, type SHUTDOWN
SUBSYSTEM RESTART at the CLUI prompt to reboot both controllers.
If there is a drive missing, enter command SHOW PHYSICAL_DISK * ALL_ATTRIBUTES.
Then search through the list to find out which slot is not reporting
Figure 29. Physical Disk List Example Screen
2.3.6

Installing Licensed Features

Before creating storage pools and virtual disks, you should install any licensed features (such as
RAID 6 and SATAssure) and activate the associated licenses.
License key generation requires that you have your feature license number, JBOD enclosure serial
number, and controller ID information. To complete license key generation, go to the SGI licensing
site, http://www.sgi.com/support/licensing/special.html.
See the SGI customer letter that accompanies your feature license order for licensing instructions.
0 0 7 - 5 5 3 3 - 0 0 1
RAID$ show unassigned_pool all_attributes
OID: 0x1800ffff
Type: UNASSIGNED
Capacity: 42270720 MBs
Failed Capacity: 0 MBs
Total Phy Disks 60
RAID$ show physical_disk * all_attributes
OID: 0x20a7003f
Pool OID: UNASSIGNED
Capacity: 704512 MBs (0x56000000 blocks)
Raw Capacity: 715404 MBs (0x575466f0 blocks)
Block Size: 512
Enabled Disk Ch: 0x27 0x22
Disk Slot: 1:42
Vendor ID: Hitachi
Product ID: Hitachi HUA721075KLA330
Product Revision: GK8OAB0A
Serial Number: GTF200P8GBVPXF
Health State: GOOD
Rotation Speed: 7200 RPM
Device Type: SATA
Member State: UNASSIGNED
Spare: FALSE
Failed: FALSE
UUID: 0x5000cca215c564560
Configuring the InfiniteStorage 6120
.
(Figure 28)
.
(Figure 29)
