Silicon Graphics InfiniteStorage 6120 User Manual page 88

Physical, Power & Environmental
InfiniteStorage 6120 chassis dimensions
(H×W×D)
InfiniteStorage 6120 chassis weight
Electrical/AC
Power consumption (maximum current)
Power consumption (average current)
Operating environment
(temperature / relative humidity)
Non-operating environment
(temperature/ relative humidity)
Cooling (maximum, peak, average)
Certification
0 0 7 - 5 5 3 3 - 0 0 1
7.0" (18 cm) × 17.56" (45 cm) × 37" (94 cm)
120 lbs (54.5 kg) without drives,
240 lbs (109.1 kg) with drives
200-240 V @ 47-63 Hz
10.3A @ 230VAC
7.5A @ 230VAC
5 °C to 35 °C / 20% - 80%, non-condensing
-10 °C to 35 °C / 20% - 80%, non-condensing
13324 BTU/h, 6560 BTU/h, 5973 BTU/h
UL, CE, CUL, FCC
78
