To monitor the rebuild progress
Figure 94. Display Rebuild Progress
To show the storage pool information
ALL_ATTRIBUTES. Once the rebuild is complete, the status of storage pool will return to
"NORMAL".
Figure 95. Display Storage Pool Information
4.4.2
Drive Replacement
Upon completion of a rebuild, the spare drive becomes a member of the storage pool, replacing the
failed drive. After you have replaced the failed drive with a new drive, the new drive is added to the
unassigned pool. It is recommended that you assign this new drive to the spare pool to "replace" the
spare drive that has been used.
4.4.3
Spare Not Available
When a drive is failed by the system and there is no spare drive available, you need to replace the
failed drive immediately. After you have replaced the failed drive with a new drive, you can initiate
a rebuild as described below:
1.
Enter command SHOW UNASSIGNED_POOL * ALL to identify the new drive's index name.
2.
Enter command ASSIGN PHYSICAL_DISK <new-disk-id> TO_POOL <pool-id>
SET_SPARE where <new-disk-id> is the index name of the replacement drive and <pool-id> is
the OID of the storage pool that had the failed drive.
0 0 7 - 5 5 3 3 - 0 0 1
(Figure 94)
RAID$ show job * all_attributes
OID:
0x2b050003
Target:
0x19b40003
Type:
REBUILD
Status:
RUNNING
Priority:
80
Fraction Complete:12%
RAID$ show pool 3 all_attributes
OID:
0x19b40003
Type:
STORAGE
Name:
raid 5 set
Chunk Size:
64KB (0x80 blocks)
Block Size:
0x200
RAID Type:
RAID5
Free Raid5 Capacity:
2752512 MBs
Total Capacity:
3522560 MBs
UUID:
0x00
Global Spare Pool:
0x1a0f000a
Initializing:
FALSE
Rebuilding:
TRUE
Paused:
FALSE
AutoWriteLock:
FALSE
Data Lost:
FALSE
Current Home:
0x0015b2a122b20000
Future Home:
0xffffffffffffffff
Preferred Home:
0xffffffffffffffff
BkgdJob OID:
0x2b050003
BkgdJob Priority:
80%
Total Phy Disks
5
State:
NOREDUNDANCY
Member Size:
704512 MB
pID
State
UUID
0x0191
RBLD
0x5000cca215c56e02
0x004e
NORM
0x5000cca215c5709c
0x0040
NORM
0x5000cca215c54c71
0x0041
NORM
0x5000cca215c5675c
0x0042
NORM
0x5000cca215c56e55
, enter command SHOW JOB * ALL_ATTRIBUTES
, enter command SHOW POOL <id>
(Figure 95)
0x00000000
0x00000000
0x00000000
Spare Drive Rebuilding
Recovering from a Drive Failure
71
