3. Attach the two (2) rail kits to your rack as shown in
space for the unit—bottom of screw plate aligns to bottom of InfiniteStorage 6120 chassis.
At the front, use one (1) screw plate, one (1) shelf locking bracket (installed from behind), and
six (6) #10 screws.
For the rear end, use one (1) screw plate and four (4) #10 screws.
4. If the depth of your rack is more than 25.5 inches (647 mm), attach the two (2) cable
management arm (CMA) brackets to the rear end of the rail kits
Attach Screw Plate
with (6) #10 Screws
0 0 7 - 5 5 3 3 - 0 0 1
Figure 16. Attach Rail Kits to Rack
Shelf Locking Bracket
installed from Behind
Setting Up the InfiniteStorage 6120
Figure 16. Make sure you leave enough
.
(Figure 16)
Attach (2) CMA Brackets
Attach Screw Plate
with (4) #10 Screws
