Model Numbers; Transmitter - Magnetrol eclipse Enhanced Model 705 Installation And Operating Manual

8.0

Model Numbers

8.1

Transmitter

BASIC MODEL NUMBER
705 ECLIPSE Guided Wave Radar Level Transmitter
POWER
5
7 0 5 5
57-642 ECLIPSE Model 705 Guided Wave Radar Transmitter for Hygienic Industries
24 VDC, Two-wire
SIGNAL OUTPUT
1 4–20 mA with HART
2 F fieldbus
OUNDATION
3 PROFIBUS PA Digital Communication (English Only)
OPTIONS
0 None – SIL 1 Standard Electronics (SFF=84.5%)
SIL 2 (Certified) Enhanced Electronics (SFF=91%) ➀
A
ACCESSORIES
0 Digital display and keypad with blind cover
A Digital display and keypad with window cover
MOUNTING/CLASSIFICATION
D
™ Digital Communication (English only)
Integral, General Purpose & Intrinsically Safe
1
(FM & CSA), Non-incendive (Class I, Div. 2)
Remote, General Purpose & Intrinsically Safe
2
(FM & CSA), Non-incendive (Class I, Div. 2)
3 Integral, Explosion Proof (FM & CSA) & Non-incendive
4 Remote, Explosion Proof (FM & CSA) & Non-incendive
Integral, General Purpose & Intrinsically Safe
A
(ATEX & JIS EEx ia IIC T4)
Remote, General Purpose & Intrinsically Safe
B
(ATEX & JIS EEx ia IIC T4)
Integral, Explosion Proof (ATEX EEx d [ia] IIC T6)
C
(must be ordered with Conduit Connection Codes 0 and 1)
Remote, Explosion Proof (ATEX EEx d [ia] IIB T6)
(must be ordered with Conduit Connection Codes 0 and 1)
E Integral, Non-incendive (ATEX EEx n II T4..6)
F Remote, Non-incendive (ATEX EEx n II T4..6)
HOUSING
1 Cast aluminum, dual compartment, 45° angle
304 stainless steel, single compartment ➁
3
7 Cast aluminum, dual compartment, 12-foot remote
304 stainless steel, single compartment, 12-foot remote ➀
9
CONDUIT CONNECTION
0 3 ⁄ " NPT
4
1 M20
" NPT ➂
4 1 ⁄
2
➀ Not available with Model 7xH Probe
➁ Only available with conduit connection code 4
➂ Not available with explosion proof Mounting/Classification
codes 3, 4, C, D.
45
