2.6.5.1 Measurement Type: Level Only (Loop Control = Level)
Display
DispFact
(select)
33
History
(current status)
34
Run Time
35
History Reset
36
HF cable
(select)
37
FidTicks
xxxx
3
FidSprd
39
Fid Type
(select)
40
Fid Gain
xxx
41
Window
xxx
42
Conv Fct
xxxx
43
Scl Ofst
xxx
44
Neg Ampl
xxx
45
Pos Ampl
xxx
46
Signal
xxx
47
Compsate
(select)
4
DrateFct
xxxx
49
Targ Ampl
xxxx
50
Targ Tks
xxxx
51
Targ Cal
xxxx
52
OperMode
(select)
53
7xKCorr
xxx
54
ElecTemp
xxx C
55
Max Temp
xxx C
56
Min Temp
xxx C
57
SZ Hyst
xx.x lu
5
18
Action
Select Yes to display factory
parameter menus
Press Enter to view history
of exceptions
Press Enter and select yes
to clear history
Superuser Parameter
Diagnostic Display
Superuser Parameter
Superuser Parameter
Factory Parameter
Factory Parameter
Factory Parameter
Superuser Password
Superuser Password
Diagnostic Display
Superuser Password
Diagnostic Display
Diagnostic Display
Diagnostic Display
Diagnostic Display
Superuser Password
Superuser Password
Diagnostic Display
Superuser Password
Superuser Password
Superuser Password
57-642 ECLIPSE Model 705 Guided Wave Radar Transmitter for Hygienic Industries
Comment
Diagnostic Display
Similar to SZ Alarm Reset
Select from 3-foot or 12-foot (84 cm or 366 cm) remote
Time of flight from start of ramp to fiducial
Select from positive or negative
(Selection only allowed for some probes)
Amount of gain applied to the fiducial signal
Calibration parameter
Calibration parameter
Diagnostic parameter
Diagnostic parameter
Indication of level signal amplitude
Select from None, Manual, Auto
Compsate = Auto. Velocity derating factor for Model 7xS Steam
probe
Compsate = Auto. Indication of steam reference target amplitude
Compsate = Auto. Measured time of flight from fiducial to steam
reference target
Compsate = Auto. Calibrated time of flight from fiducial to target
in room temperature air
Compsate = Auto. Select from Run, Cal, Off
Distance in mm from fiducial to user reference point
(7xK probe characteristic)
Present temperature in electronics compartment
(degrees Celsius)
Maximum electronics temperature recorded
Minimum electronics temperature recorded
