2
Probe Mount
20 mA
9
(100% Point)
Probe Model
1
Probe Length
Dielectric
7
of Medium
4 mA Level
8
(0%-point)
Level Offset
NOTE: A small transition zone [0–6" (0–15cm)]
may exist at the top and bottom of the
probe. See Specifications, Section 7.4.
57-642 ECLIPSE Model 705 Guided Wave Radar Transmitter for Hygienic Industries
1.4
1. Power-up the transmitter.
2. Remove the transmitter cover (the lower electronic compart-
Enter
Down
3. Use the Up or Down Arrow (
Up
4. Press the Enter Arrow (
5. Use the Up or Down Arrow (
6. Press the Enter Arrow (
7. After entering the last value, allow 10 seconds before
①
②
4
In or Cm
Æ
Ø
5
∞
±
6
≤
⑧
⑨

QuickStart Configuration

The ECLIPSE transmitter is configured with default
values from the factory but can be reconfigured in the shop
(disregard any fault messages due to unattached probe). The
minimum configuration instructions required in the field
follow. Use the information from the operating parameters
table in Section 1.1.2 before beginning configuration.
The display changes every five seconds to show one of four
values: Status, Level, %Output, and Loop current.
ment of the dual compartment aluminum version).
step of the configuration program to the next step.
first line of the display changes to an exclamation point (!).
decrease the value in the display or to scroll through the
choices.
to the next step of the configuration program (the default
password is 0).
removing power from the transmitter.
The following configuration entries are the minimum required for
configuration (the default password is 0 from the LCD/keypad).
PrbModel
(select)
Select the Probe Model to be used
Model 705: 7xF-E or 7xH-X
PrbMount
(select)
Select the type of Probe Mounting to vessel (Flange)
MeasType
(select)
Select from Level Only, Level and Volume, Interface Level
or Interface Level and Volume.
Lvl Units
xxx Select the Units of measurement for the level readout (inches,
cm, feet or meters). Not included on Model 705 Fieldbus.
Probe Ln
xxx.x
Enter the exact Probe Length.
LvlOfst
xxx.x
Enter the Level Offset value. Refer to Section 2.6.6 for
further information. (The unit is shipped from the factory
with offset = 0; i.e., all measurements are referenced to
the bottom of the probe).
Dielctrc
Enter the Dielectric range for the material to be measured.
(select)
(Typically 10–100 for hygienic applications)
Set 4mA
xxx.x Enter the level value (0%-point) for the 4 mA point (not
included on Model 705 fieldbus).
Set 20mA
xxx.x Enter the level value (100%-point) for the 20 mA point (not
included on Model 705 fieldbus).
) keys to move from one
) key. The last character in the
) keys to increase or
) key to accept a value and move
