7.5

Physical

inches (mm)
4.43
(113)
45° View
4.28
(109)
Eclipse
2.75
(70)
2.00
(51)
3.50
(89)
44
45 View
4.38
(111)
Housing
®
(45° View)
3.08
2.12
(78)
(54)
2.53
(64)
Elect.
Conn.
Qty. 2
3.75
3.00
(95)
(76)
2 Holes
.38 (10) Dia.
Eclipse
Remote Configuration
®
8.43
(214)
4.94
(126)
43°
33.00 or 144.00
(838 or 3650)
57-642 ECLIPSE Model 705 Guided Wave Radar Transmitter for Hygienic Industries
2.17
(55)
Process
Connection
Ø 0.50" (12) Rod
Ø 0.25" (6) for ¾" Triclamp
Eclipse
with 7xF-E Probe
®
Hygienic Connection
3.02
(77)
2.53
(64)
7xF-E:
8.94
Electrical
(227)
Connection
7xH:
9.25
(235)
Probe
Insertion
Length
