Sample Calibration Verification Document - Magnetrol eclipse Enhanced Model 705 Installation And Operating Manual

Mark1 (0 cm)
Mark2 (10 cm)
Mark8 (90 cm)
Mark9 (110 cm)
Mark10 (110 cm)
Mark11 (120 cm)
Mark19 (180 cm)
Mark20 (190 cm)
Mark21 (200 cm)
Certified
Date
57-642 ECLIPSE Model 705 Guided Wave Radar Transmitter for Hygienic Industries
required range, as determined by the User Requirement
Specification (URS), the transmitter passes calibration veri-
fication and can be reinstalled on the process.
If the transmitter under test fails calibration verification, the
transmitter must be installed on the vessel and the
probe/transmitter must undergo a complete wet calibration.
After a successful wet calibration is completed, the transmit-
ter should be removed and taken to the dry calibration veri-
fication bench where a NEW Initial Baseline Verification
must be performed. The old Initial Baseline Verification is
now invalid as adjustments have been made to the transmit-
ter during wet calibration.
9.3

Sample Calibration Verification Document

If the accuracy is inside has limits "URS" (User
Requirement Specifications), the ECLIPSE passes.
NOTE: The accuracy required is the accuracy required per the
URS – NOT the standard accuracy of ECLIPSE!
Frequency of calibration verification is determined based on
experience, process conditions, and criticality of the mea-
surement.
INITIAL 2012
0
0
0
0
0
0
25,2 liter
45,7 liter
475,3 liter
500,2 liter
500,2 liter
Miller
11.1.2010
2013
0,1 liter
25,1 liter
45,8 liter
475 liter
500,0 liter
500,0 liter
Smith
15.1.2011
2014
49
