eBOX635-881-FL Series User's Manual
Step 5 Please refer to the following photo to connect SATA power and signal cables.
Step 6 Fasten screws of HDD drive bay.
2.2

Installing the Memory Module

Step 1 Turn off the system, and unplug the power cord.
Step 2 Turn the system upside down to locate screws at the Bottom, loosen screws.
Step 3 Remove the bottom cover to locate the bracket screws. Then loosen four
screws to take out the bracket directly.
12
Hardware Installation
