eBOX635-881-FL Series User's Manual
2.4

Installing the Express Mini Card

Step 1 Turn off the system, and unplug the power cord.
Step 2 Turn the system upside down to locate screws at the Bottom, loosen screws.
Step 3 Remove the bottom cover to locate the Express Mini Card slot.
Hardware Installation
17
