NANO-KBN-i1
NANO-KBN-i1 CPU Card
MODEL:
NANO-KBN-i1
EP IC S BC s u p p o rts AMD® Em b e d d e d G-S e rie s S o C with
VGA/HDMI/LVDS , Du a l P CIe Gb E, US B 3.0, P CIe Min i, S ATA 6Gb /s ,
m S ATA, COM, iRIS -1010, HD Au d io a n d Ro HS
Us e r Ma n u a l
Page I
Re v. 1.00 - 11 Ma rc h , 2014

Advertisement

Table of Contents
loading

Related Manuals for IEI Technology NANO-KBN-i1

Summary of Contents for IEI Technology NANO-KBN-i1

  • Page 1 NANO-KBN-i1 NANO-KBN-i1 CPU Card MODEL: NANO-KBN-i1 EP IC S BC s u p p o rts AMD® Em b e d d e d G-S e rie s S o C with VGA/HDMI/LVDS , Du a l P CIe Gb E, US B 3.0, P CIe Min i, S ATA 6Gb /s ,...
  • Page 2 NANO-KBN-i1 Re vis io n Date Version Changes 11 March, 2014 1.00 Initial release Page II...
  • Page 3 NANO-KBN-i1 Co p yrig h t COP YRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer.

  • Page 4: Table Of Contents

    PTIONAL TEMS 3 CONNECTORS ......................14 3.1 P ..............15 ERIPHERAL NTERFACE ONNECTORS 3.1.1 NANO-KBN-i1 Layout ..................15 3.1.2 Peripheral Interface Connectors ..............15 3.1.3 External Interface Panel Connectors ............... 17 3.2 I ..............17 NTERNAL ERIPHERAL ONNECTORS 3.2.1 12V DC-IN Power Connector ................17 3.2.2 Audio Connector ....................
  • Page 5 NANO-KBN-i1 3.2.11 Keyboard and Mouse Connector ..............26 3.2.12 LAN LED Connectors ..................27 3.2.13 LVDS Backlight Inverter Connector .............. 27 3.2.14 LVDS LCD Connector ................... 28 3.2.15 LVDS LED connector ..................29 3.2.16 PCIe Mini Card Slot ..................30 3.2.17 Power Button Connector ................
  • Page 6 NANO-KBN-i1 4.5.1 Audio Kit Installation ..................55 4.5.2 SATA Drive Connection ................... 56 4.5.3 Single RS-232 Cable ..................57 4.6 E ........... 58 XTERNAL ERIPHERAL NTERFACE ONNECTION 4.6.1 HDMI Display Device Connection ..............59 4.6.2 LAN Connection ....................59 4.6.3 USB Connection ....................60 4.6.4 VGA Monitor Connection ................
  • Page 7 NANO-KBN-i1 5.6 S ......................... 92 ECURITY 5.7 E ......................... 92 A BIOS MENU OPTIONS ..................... 94 B ONE KEY RECOVERY ..................... 97 B.1 O ..............98 ECOVERY NTRODUCTION B.1.1 System Requirement ..................99 B.1.2 Supported Operating System ................. 100 B.2 S ................
  • Page 8 NANO-KBN-i1 E.1 H IPB P AZARDOUS ATERIAL ISCLOSURE ABLE FOR RODUCTS ERTIFIED AS HS C 2002/95/EC W ........142 OMPLIANT NDER ITHOUT ERCURY Page VIII...
  • Page 9 NANO-KBN-i1 Lis t o f Fig u re s Figure 1-1: NANO-KBN-i1 ......................2 Figure 1-2: Connectors ........................4 Figure 1-3: Dimensions (mm) ......................5 Figure 1-4: Data Flow Diagram ...................... 6 Figure 3-1: Connector and Jumper Locations ................15 Figure 3-2: 12V DC-IN Power Connector Location ..............18 Figure 3-3: Audio Connector Location ..................19...
  • Page 10 NANO-KBN-i1 Figure 3-28: System Fan Connector Locations .................40 Figure 3-29: TPM Connector Location ..................41 Figure 3-30: USB Connector Locations ..................42 Figure 3-31: External Peripheral Interface Connector ..............43 Figure 3-32: LAN Connector ......................44 Figure 3-33: VGA Connector .......................46 Figure 4-1: SO-DIMM Installation ....................50 Figure 4-2: AT/ATX Mode Select Switch Location ..............51...
  • Page 11 NANO-KBN-i1 Figure B-17: Compress Image ....................111 Figure B-18: Image Creation Confirmation ................112 Figure B-19: Image Creation Complete ..................112 Figure B-20: Image Creation Complete ..................112 Figure B-21: Press Any Key to Continue .................113 Figure B-22: Partitions for Linux ....................114 Figure B-23: Manual Recovery Environment for Linux ............115 Figure B-24: Access menu.lst in Linux (Text Mode) ...............115...
  • Page 12 NANO-KBN-i1 Lis t o f Ta b le s Table 1-1: NANO-KBN-i1 Model Variations .................. 2 Table 1-2: Technical Specifications ....................9 Table 3-1: Peripheral Interface Connectors ................17 Table 3-2: Rear Panel Connectors ....................17 Table 3-3: 12V DC-IN Power Connector Pinouts ...............18 Table 3-4: Audio Connector Pinouts ..................19...
  • Page 13 NANO-KBN-i1 Table 3-30: LAN Pinouts ......................44 Table 3-31: Connector LEDs ......................44 Table 3-32: USB 2.0 Port Pinouts (USB1) ...................45 Table 3-33: USB 3.0 Port Pinouts (USB2) ...................45 Table 3-34: VGA Connector Pinouts ...................46 Table 4-1: AT/ATX Mode Select Switch Settings ...............51 Table 4-2: Clear CMOS Button Settings ..................52...
  • Page 14 NANO-KBN-i1 Lis t o f BIOS Me n u s BIOS Menu 1: Main ........................67 BIOS Menu 2: Advanced ......................69 BIOS Menu 3: ACPI Configuration ....................69 BIOS Menu 4: RTC Wake Settings ....................70 BIOS Menu 5: Trusted Computing ....................71 BIOS Menu 6: CPU Configuration ....................72 BIOS Menu 7: IDE Configuration ....................73...

  • Page 15: Introduction

    NANO-KBN-i1 Chapter In tro d u c tio n P a g e 1...

  • Page 16: Introduction

    It supports one 204-pin 1600/1333 MHz DDR3 SO-DIMM up to 8.0 GB. The NANO-KBN-i1 supports dual display via VGA, HDMI and an internal LVDS connector. Expansion and I/O include two USB 3.0 connectors on the rear panel, four USB 2.0 connectors by pin header, two USB 2.0 connectors on the rear panel and two SATA 6Gb/s...

  • Page 17: Features

    NANO-KBN-i1 1.3 Fe a tu re s Some of the NANO-KBN-i1 motherboard features are listed below:  AMD® embedded G-Series SoC EPIC SBC supports  Dual independent display support  One 204-pin 1600/1333 MHz dual-channel DDR3 & DDR3L SDRAM unbuffered SO-DIMM support up to 8GB ...

  • Page 18: Connectors

    NANO-KBN-i1 1.4 Co n n e c to rs The connectors on the NANO-KBN-i1 are shown in the figure below. Figure 1-2: Connectors P a g e 4...

  • Page 19: Dimensions

    NANO-KBN-i1 1.5 Dim e n s io n s The dimensions of the board are listed below: Figure 1-3: Dimensions (mm) P a g e 5...

  • Page 20: Data Flow

    NANO-KBN-i1 1.6 Da ta Flow Figure 1-4 shows the data flow between the system chipset, the CPU and other components installed on the motherboard. Figure 1-4: Data Flow Diagram P a g e 6...

  • Page 21: Technical Specifications

    NANO-KBN-i1 1.7 Te c h n ic a l Sp e c ific a tio n s NANO-KBN-i1 technical specifications are listed below. S p e c ific a tio n NANO-KBN-i1 S o C AMD® Embedded G-Series SoC GX-415GA on-board SoC (1.5GHz, quad-core, 2MB cache, TDP=15W) GX-210HA on-board SoC (1.0GHz, dual-core, 1MB cache,...
  • Page 22 NANO-KBN-i1 S p e c ific a tio n NANO-KBN-i1 Dis p la y Ou tp u t 1 x VGA (2560x1600) 1 x HDMI via v1.4a compliant (2560x1600) 1 x 24-bit dual channel LVDS by CH7511B DP to LVDS...

  • Page 23: Table 1-2: Technical Specifications

    NANO-KBN-i1 S p e c ific a tio n NANO-KBN-i1 S e ria l ATA 2 x SATA 6G/s with 5V SATA power connector En viro n m e n ta l a n d P o we r S p e c ific a tio n s...

  • Page 24: Unpacking

    NANO-KBN-i1 Chapter Un p a c kin g P a g e 10...

  • Page 25: Anti Static Precautions

    Only handle the edges of the PCB: Don't touch the surface of the motherboard. Hold the motherboard by the edges when handling. 2.2 Un pa c kin g P re c a u tio n s When the NANO-KBN-i1 is unpacked, please do the following:  Follow the antistatic guidelines above.

  • Page 26: Packing List

    If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the NANO-KBN-i1 was purchased from or contact an IEI sales representative directly by sending an email to sales@iei.com.tw.

  • Page 27: Optional Items

    NANO-KBN-i1 One Key Recovery CD Quick Installation Guide 2.4 Op tio n a l Ite m s The following are optional components which may be separately purchased: Ite m a n d P a rt Nu m b e r...

  • Page 28: Connectors

    NANO-KBN-i1 Chapter Co n n e c to rs P a g e 14...

  • Page 29: Peripheral Interface Connectors

    3.1 P e rip h e ra l In te rfa c e Co n n e c to rs This chapter details all the jumpers and connectors. 3.1.1 NANO-KBN-i1 La yo u t The figures below show all the connectors and jumpers.
  • Page 30 NANO-KBN-i1 Chassis intrusion connector 2-pin header CHASSIS1 DDR3 SO-DIMM slot DDR3 SO-DIMM slot DIMM1 Digital I/O connector 10-pin header DIO1 Front panel connector 6-pin wafer IPMI LED connector 2-pin header ID_LED1 iRIS-1010 module slot iRIS-1010 module slot IPMI1 Keyboard and mouse connector...

  • Page 31: External Interface Panel Connectors

    3.2 In te rn a l P e rip h e ra l Co n n e c to rs The section describes all of the connectors on the NANO-KBN-i1. 3.2.1 12V DC-IN P owe r Con n e c to r...

  • Page 32: Audio Connector

    NANO-KBN-i1 Figure 3-2: 12V DC-IN Power Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION 12V-IN 12V-IN Table 3-3: 12V DC-IN Power Connector Pinouts 3.2.2 Au d io Co n n e c to r CN La b e l: AUDIO1...

  • Page 33: Battery Connector

    NANO-KBN-i1 Figure 3-3: Audio Connector Location P IN NO. DES CRIP TION P IN NO. DES CRIP TION LINEOUT1R LINE1R LINEOUT1L LINE1L FMIC1R FMIC1L Table 3-4: Audio Connector Pinouts 3.2.3 Ba tte ry Co n n e c to r...

  • Page 34: Brightness Button Connector

    NANO-KBN-i1 Figure 3-4: Battery Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION VBATT Table 3-5: Battery Connector Pinouts 3.2.4 Brig h tn e s s b u tto n c o n n e c to r CN La b e l:...

  • Page 35: Chassis Intrusion Connector

    NANO-KBN-i1 PIN NO. DESCRIPTION PIN NO. DESCRIPTION PWRON BLUP BLDN Table 3-6: Brightness Button Connector Pinouts 3.2.5 Ch a s s is In tru s io n Con n e c to r CN La b e l: CHAS S IS 1...

  • Page 36: Ddr3 So-Dimm Slot

    NANO-KBN-i1 Description +V3.3A_EC CHASSIE_EC Table 3-7: Chassis Intrusion Connector Pinouts 3.2.6 DDR3 S O-DIMM S lo t CN La b e l: DIMM1 DDR3 SO-DIMM slot CN Typ e : CN Lo c a tio n : See Figure 3-7 The DDR3 SO-DIMM slot is for DDR3 SO-DIMM memory module.

  • Page 37: Front Panel Connector

    NANO-KBN-i1 See Table 3-8 CN P in o u ts : The digital I/O connector provides programmable input and output for external devices. The digital I/O provides 4-bit output and 4-bit input. Figure 3-8: Digital I/O Connector Location PIN NO.

  • Page 38: Ipmi Led Connector

    NANO-KBN-i1 Figure 3-9: Front Panel Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION PWR_LED+ PWR_LED- HDD_LED+ HDD_LED- Table 3-9: Front Panel Connector Pinouts 3.2.9 IP MI LED Co n n e c to r CN La b e l: ID_LED1...

  • Page 39: Iris-1010 Module Slot

    NANO-KBN-i1 Description ID_LED+ ID_LED- Table 3-10: IPMI LED Connector Pinouts 3.2.10 iRIS -1010 m o d u le s lot CN La b e l: IP MI1 IPMI 2.0 slot CN Typ e : CN Lo c a tio n : See Figure 3-11 The iRIS-1010 module slot allows installation of the iRIS-1010 module.

  • Page 40: Keyboard And Mouse Connector

    2.0 module. DO NOT install other modules into the iRIS-1010 module slot. Doing so may cause damage to the NANO-KBN-i1. 3.2.11 Ke yb o a rd a n d Mo u s e Co n n e c to r...

  • Page 41: Lan Led Connectors

    NANO-KBN-i1 Description Keyboard Clock Table 3-11: Keyboard and Mouse Connector Pinouts 3.2.12 LAN LED Co n n e c to rs CN La b e l: LED_LAN2, LED_LAN3 2-pin header CN Typ e : CN Lo c a tio n :...

  • Page 42: Lvds Lcd Connector

    NANO-KBN-i1 5-pin wafer CN Typ e : See Figure 3-14 CN Lo c a tio n : See Table 3-13 CN P in o u ts : The backlight inverter connector provides power to an LCD panel. Figure 3-14: Backlight Inverter Connector Location...

  • Page 43: Lvds Led Connector

    NANO-KBN-i1 Figure 3-15: LVDS Connector Location Description Description A0P_L A0M_L A1P_L A1M_L A2P_L A2M_L CLK1P_L CLK1M_L A3P_L A3M_L A4P_L A4M_L A5P_L A5M_L A6P_L A6M_L CLK2P_L CLK2M_L A7P_L A7M_L Table 3-14: LVDS Connector Pinouts 3.2.15 LVDS LED c o n ne c to r...

  • Page 44: Pcie Mini Card Slot

    NANO-KBN-i1 The backlight inverter connector provides power to an LCD panel. Figure 3-16: LVDS LED Connector Location Description VCC33 OLED VCC33 GLED Table 3-15: LVDS LED Connector Pinouts 3.2.16 P CIe Min i Ca rd S lo t CN La b e l:...

  • Page 45: Power Button Connector

    NANO-KBN-i1 Figure 3-17: PCIe Mini Card Slot Location 3.2.17 P owe r Bu tto n Co n n e c to r CN La b e l: P WR_BTN1 2-pin wafer CN Typ e : CN Lo c a tio n :...

  • Page 46: Reset Button Connector

    NANO-KBN-i1 3.2.18 Re s e t Bu tto n Co n n e c to r CN La b e l: RS T_BTN1 2-pin wafer CN Typ e : CN Lo c a tio n : See Figure 3-19 See Table 3-17...

  • Page 47: Rs-422/485 Serial Port Connector

    NANO-KBN-i1 Figure 3-20: RS-232 Serial Port Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION NDCD NDSR NRTS NCTS NDTR Table 3-18: RS-232 Serial Port Connector Pinouts 3.2.20 RS -422/485 S e ria l P ort Co n n e c to r...

  • Page 48: Sata 6Gb/S Drive Connector

    NANO-KBN-i1 Figure 3-21: RS-422/485 Connector Location Description Description RXD485# RXD485+ TXD485+ TXD485# Table 3-19: RS-422/485 Connector Pinouts Use the optional RS-422/485 cable to connect to a serial device. The pinouts of the DB-9 connector are listed below. RS-422 Pinouts RS-485 Pinouts Table 3-20: DB-9 RS-422/485 Pinouts 3.2.21 S ATA 6Gb /s Drive Co n n e c to r...

  • Page 49: Sata Power Connector

    NANO-KBN-i1 The SATA 6Gb/s drive connector is connected to a SATA 6Gb/s drive. The SATA 6Gb/s drive transfers data at speeds as high as 6Gb/s. Figure 3-22: SATA 6Gb/s Drive Connector Location 3.2.22 S ATA P o we r Co n n e c to r...

  • Page 50: Smbus Connector

    NANO-KBN-i1 Figure 3-23: SATA Power Connector Location PIN NO. DESCRIPTION Table 3-21: SATA Power Connector Pinouts 3.2.23 S MBUS Co n n e c to r CN La b e l: CN3, CN4 4-pin wafer CN Typ e : See Figure 3-24...

  • Page 51: Spdif Connector

    NANO-KBN-i1 Figure 3-24: SMBUS Connectors Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION SMBDATA SMBCLK Table 3-22: SMBUS Connectors Pinouts 3.2.24 S P DIF Co n n e c to r CN La b e l: S P DIF1 5-pin header...

  • Page 52: Spi Flash Connector (Bios)

    NANO-KBN-i1 DESCRIPTION SPDIF OUT SPDIF IN Table 3-23: SPDIF Connector Pinouts 3.2.25 S P I Fla s h Co n n e c to r (BIOS ) CN La b e l: S P I1 CN Typ e : 6-pin wafer...

  • Page 53: Spi Flash Connector (Ec)

    NANO-KBN-i1 Description SPI_CLK SPI_DATAOUT Table 3-24: SPI Flash Connector (BIOS) Pinouts 3.2.26 S P I Fla s h Co n n e c to r (EC) CN La b e l: CN Typ e : 2-pin header CN Lo c a tio n :...

  • Page 54: Tpm Connector

    NANO-KBN-i1 See Table 3-26 CN P in o u ts : The fan connector attaches to a system cooling fan. Figure 3-28: System Fan Connector Locations PIN NO. DESCRIPTION PIN NO. DESCRIPTION +12V FANIN FANOUT Table 3-26: System Fan Connector Pinouts 3.2.28 TP M Co n n e c to r...

  • Page 55: Usb Connector

    NANO-KBN-i1 Figure 3-29: TPM Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION LPC_CLK1 LFRAME# LPC_RST# LAD3 LAD2 +3.3V LAD1 LAD0 SCLK0 SDATA0 +3.3V_DUAL SERIRQ LPC_CLKRUN# LPCPD# LDRQ#0 Table 3-27: TPM Connector Pinouts 3.2.29 US B Co n n e c to r...

  • Page 56: External Peripheral Interface Connector Panel

    3.3 Exte rn a l P e rip h e ra l In te rfa c e Co n n e c to r P a n e l Figure 3-31 shows the NANO-KBN-i1 external peripheral interface connector (EPIC) panel. The EPIC panel consists of the following: ...

  • Page 57: Hdmi Connector

    NANO-KBN-i1 Figure 3-31: External Peripheral Interface Connector 3.3.1 HDMI Co n n e c to r HDMI1 CN La b e l: HDMI type A connector CN Typ e : See Figure 3-31 CN Lo c a tio n :...

  • Page 58: Usb Connectors

    CN Lo c a tio n : See Figure 3-31 CN P in o u ts : See Table 3-32 and Table 3-33 The NANO-KBN-i1 has two external USB 2.0 ports and two external USB 3.0 ports. P a g e 44...

  • Page 59: Vga Connector

    NANO-KBN-i1 The pinouts of USB 2.0 connectors are shown below. PIN NO. DESCRIPTION PIN NO. DESCRIPTION POWER DATA0_N DATA0_P POWER DATA1_N DATA1_P Table 3-32: USB 2.0 Port Pinouts (USB1) The pinouts of USB 3.0 connectors are shown below. PIN NO.

  • Page 60: Figure 3-33: Vga Connector

    NANO-KBN-i1 DESCRIPTION DESCRIPTION BLUE CRT_VCC 5VDDCDA VGA_HSYNC VGA_VSYNC 5VDDCLK Table 3-34: VGA Connector Pinouts Figure 3-33: VGA Connector P a g e 46...

  • Page 61: Installation

    NANO-KBN-i1 Chapter In s ta lla tio n P a g e 47...

  • Page 62: Anti - Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the NANO-KBN-i1. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the NANO-KBN-i1 or any other electrical component is handled, the following anti-static precautions are strictly adhered to.
  • Page 63  Turn all power to the NANO-KBN-i1 off: When working with the NANO-KBN-i1, make sure that it is disconnected from all power supplies and that no electricity is being fed into the system. Before and during the installation of the NANO-KBN-i1 DO NOT: ...

  • Page 64: So-Dimm Installation

    NANO-KBN-i1. Please make sure the purchased SO-DIMM complies with the memory specifications of the NANO-KBN-i1. SO-DIMM specifications compliant with the NANO-KBN-i1 are listed in the specification table of Chapter 1. To install an SO-DIMM, please follow the steps below and refer to Figure 4-1.

  • Page 65: System Configuration

    NANO-KBN-i1 4.4 S ys te m Co n fig u ra tio n The system configuration is controlled by buttons, jumpers and switches. The system configuration should be performed before installation. 4.4.1 AT/ATX Mo d e S e le c t S witc h...

  • Page 66: Clear Cmos Button

    CN S e ttin g s : See Table 4-2 If the NANO-KBN-i1 fails to boot due to improper BIOS settings, use the button to clear the CMOS data and reset the system BIOS information. The clear CMOS button settings are shown in Table 4-2.

  • Page 67: Table 4-3: Lvds Panel Resolution Selection

    NANO-KBN-i1 J u m p e r S e ttin g s : See Table 4-3 J u m p e r Lo c a tio n : See Figure 4-4 Selects the resolution of the LCD panel connected to the LVDS connector.

  • Page 68: Lvds Voltage Selection

    4.4.3 LVDS Vo lta g e S e le c tio n WARNING: Permanent damage to the screen and NANO-KBN-i1 may occur if the wrong voltage is selected with this jumper. Please refer to the user guide that came with the monitor to select the correct voltage.

  • Page 69: Internal Peripheral Device Connections

    This section outlines the installation of peripheral devices to the on-board connectors 4.5.1 Au d io Kit In s ta lla tio n The Audio Kit that came with the NANO-KBN-i1 connects to the audio connector on the NANO-KBN-i1. The audio kit consists of three audio jacks. Mic-in connects to a microphone.

  • Page 70: Sata Drive Connection

    0: 4.5.2 S ATA Drive Co n n e c tio n The NANO-KBN-i1 is shipped with a SATA drive cable. To connect the SATA drive to the connector, please follow the steps below. S te p 1: Locate the SATA connector and the SATA power connector.

  • Page 71: Single Rs-232 Cable

    NANO-KBN-i1 Figure 4-7: SATA Drive Cable Connection S te p 3: Connect the cable to the SATA disk. Connect the connector on the other end of the cable to the connector at the back of the SATA drive. See Figure 4-7.

  • Page 72: External Peripheral Interface Connection

    RJ-45 LAN cable  USB devices  VGA monitors To install these devices, connect the corresponding cable connector from the actual device to the corresponding NANO-KBN-i1 external peripheral interface connector making sure the pins are properly aligned. P a g e 58...

  • Page 73: Hdmi Display Device Connection

    4.6.1 HDMI Dis p la y De vic e Co n n e c tio n The HDMI connector transmits a digital signal to compatible HDMI display devices such as a TV or computer screen. To connect the HDMI cable to the NANO-KBN-i1, follow the steps below.

  • Page 74: Usb Connection

    Chapter 3. Align the connector. Align the RJ-45 connector on the LAN cable with the S te p 2: RJ-45 connectors on the NANO-KBN-i1. See Figure 4-10. Figure 4-10: LAN Connection S te p 3: Insert the LAN cable RJ-45 connector. Once aligned, gently insert the LAN cable RJ-45 connector into the on-board RJ-45 connector.

  • Page 75: Vga Monitor Connection

    4.6.4 VGA Mo n ito r Co n n e c tio n The NANO-KBN-i1 has a single female DB-15 connector on the external peripheral interface panel. The DB-15 connector is connected to a CRT or VGA monitor. To connect a monitor to the NANO-KBN-i1, please follow the instructions below.

  • Page 76: Heat Sink Enclosure

    The heat sink ensures the system remains cool and does not need addition heat sinks to cool the system. When the NANO-KBN-i1 is shipped it is secured to a heat sink with eight retention screws. If the NANO-KBN-i1 must be removed from the heat sink, the eight retention screws must be removed.

  • Page 77: Figure 4-13: Heat Sink Retention Screws

    NANO-KBN-i1 Figure 4-13: Heat Sink Retention Screws P a g e 63...

  • Page 78: Bios

    NANO-KBN-i1 Chapter BIOS P a g e 64...

  • Page 79: Introduction

    NANO-KBN-i1 5.1 In tro d u c tio n The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. NOTE: Some of the BIOS options may vary throughout the life cycle of the product and are subject to change without prior notice.

  • Page 80: Getting Help

    NANO-KBN-i1 Ke y Fu n c tio n Decrease the numeric value or make changes Page up Move to the next page Page down Move to the previous page Main Menu – Quit and do not save changes into CMOS...

  • Page 81: Main

    NANO-KBN-i1 The following sections completely describe the configuration options found in the menu items at the top of the BIOS screen and listed above. 5.2 Ma in The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered.

  • Page 82: Advanced

    NANO-KBN-i1  iWDD Ve n d o r  The iWDD Vendor displays the installed iWDD vendor. The fields in iWDD Vendor cannot be changed.  iWDD Ve rs io n  The iWDD Version displays the current iWDD version. The fields in iWDD Version cannot be changed.

  • Page 83: Acpi Settings

    NANO-KBN-i1 Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit > ACPI Settings System ACPI Parameters. > RTC Wake Settings > Trusted Computing > CPU Configuration > IDE Configuration ---------------------- : Select Screen >...

  • Page 84: Rtc Wake Settings

    NANO-KBN-i1  The caches are flushed and the CPU is powered S3 only (Suspend EFAULT to RAM) off. Power to the RAM is maintained. The computer returns slower to a working state, but more power is saved. 5.3.2 RTC Wa ke S e ttin g s The RTC Wake Settings menu (BIOS Menu 4) configures RTC wake event.

  • Page 85: Trusted Computing

    NANO-KBN-i1 selected: Wake up date Wake up hour Wake up minute Wake up second After setting the alarm, the computer turns itself on from a suspend state when the alarm goes off. 5.3.3 Tru s te d Co m p u tin g Use the Trusted Computing menu (BIOS Menu 5) to configure settings related to the Trusted Computing Group (TCG) Trusted Platform Module (TPM).

  • Page 86: Cpu Configuration

    NANO-KBN-i1  Security device support is enabled. Enable 5.3.4 CP U Co n fig u ra tio n Use the CPU Configuration menu (BIOS Menu 6) to view detailed CPU specifications and configure the CPU. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.

  • Page 87: Ide Configuration

    NANO-KBN-i1  Active processor cores Automatic mode EFAULT automatic mode  cores Active two of the processor cores processor  core Active one of the processor cores processor 5.3.5 IDE Co n fig u ra tio n Use the IDE Configuration menu (BIOS Menu 7) to change and/or set the configuration of the SATA devices installed in the system.

  • Page 88: Usb Configuration

    NANO-KBN-i1  Configures SATA devices as normal IDE device. EFAULT  AHCI Configures SATA devices as AHCI device. 5.3.6 US B Co n fig u ra tio n Use the USB Configuration menu (BIOS Menu 10) to read USB configuration information and configure the USB settings.

  • Page 89: F81866 Super Io Configuration

    NANO-KBN-i1 keyboard can control the system even when there is no USB driver loaded onto the system.  Enabled Legacy USB support enabled EFAULT  Disabled Legacy USB support disabled  Auto Legacy USB support disabled if no USB devices are connected 5.3.7 F81866 S u pe r IO Co nfig u ra tio n...

  • Page 90: Serial Port N Configuration

    NANO-KBN-i1 5.3.7.1 S e ria l P o rt n Co n fig u ra tio n Use the Serial Port n Configuration menu (BIOS Menu 10) to configure the serial port n. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
  • Page 91 NANO-KBN-i1  Serial Port I/O port address is 3F8h and the IO=3F8h; IRQ=3, 4,5,6,7,10,11,12 interrupt address is IRQ3,4,5,6,7,10,11,12  IO=2F8h; IRQ=3, Serial Port I/O port address is 2F8h and the interrupt address is IRQ3,4,5,6,7,10,11,12 4,5,6,7,10,11,12  IO=3E8h; IRQ=3, Serial Port I/O port address is 3E8h and the...
  • Page 92 NANO-KBN-i1  Serial Port I/O port address is 2E8h and the IO=2E8h; IRQ=3, 4,5,6,7,10,11,12 interrupt address is IRQ3,4,5,6,7,10,11,12 5.3.7.1.3 S e ria l P o rt 3 Co n fig u ra tio n  S e ria l P o rt [En a b le d ] Use the Serial Port option to enable or disable the serial port.
  • Page 93 NANO-KBN-i1 5.3.7.1.4 S e ria l P o rt 4 Co n fig u ra tio n  S e ria l P o rt [En a b le d ] Use the Serial Port option to enable or disable the serial port.
  • Page 94 NANO-KBN-i1  Enable the serial port Enabled EFAULT  Ch a n g e S e ttin g s [Au to ] Use the Change Settings option to change the serial port IO port address and interrupt address.  Auto...

  • Page 95: F81866 H/W Monitor

    NANO-KBN-i1  The serial port IO port address and interrupt Auto EFAULT address are automatically detected.  IO=2D8h; IRQ=10 Serial Port I/O port address is 2D8h and the interrupt address is IRQ10  IO=3E8h; IRQ=3, Serial Port I/O port address is 3E8h and the...

  • Page 96: Smart Fan Mode Configuration

    NANO-KBN-i1  P C He a lth Sta tu s The following system parameters and values are shown. The system parameters that are monitored are:  System Temperatures: CPU Temperature SYS Temperature  Fans Speeds: SYS FAN Speed  Voltages:...

  • Page 97: Bios Menu 12: Smart Fan Configuration

    NANO-KBN-i1 Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Advanced Smart Fan Mode Configuration Smart Fan Mode Select SYS_FAN Smart Fan Control [Auto Duty-Cycle Mode] SYS Temperature 1 SYS Temperature 2 SYS Temperature 3 SYS Temperature 4 --------------------- : Select Screen...

  • Page 98: Serial Port Console Redirection

    NANO-KBN-i1 5.3.9 S e ria l P o rt Co n s o le Re d ire c tio n The Serial Port Console Redirection menu (BIOS Menu 13) allows the console redirection options to be configured. Console redirection allows users to maintain a system remotely by re-directing keyboard input and text output through the serial port.

  • Page 99: Console Redirection Settings

    NANO-KBN-i1 5.3.9.1 Co n s o le Re d ire c tio n S e ttin g s The Console Redirection Settings menu (BIOS Menu 14) allows the console redirection options to be configured. The option is active when Console Redirection option is enabled.
  • Page 100 NANO-KBN-i1  Bits p e r s e c o n d [115200] Use the Bits per second option to specify the serial port transmission speed. The speed must match the other side. Long or noisy lines may require lower speeds.

  • Page 101: Chipset

    NANO-KBN-i1  Sto p Bits [1] Use the Stop Bits option to specify the number of stop bits used to indicate the end of a serial data packet. Communication with slow devices may require more than 1 stop bit. ...

  • Page 102: South Bridge Configuration

    NANO-KBN-i1 5.4.1 S o u th Brid g e Co n fig u ra tio n Use the South Bridge Configuration menu (BIOS Menu 16) to configure the South Bridge chipset. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.

  • Page 103: North Bridge Configuration

    NANO-KBN-i1  P o we r S a vin g Fu n c tio n (ERP ) [Dis a b le d ] Use the Power Saving Function (ERP) BIOS option to enable or disable the power saving function. ...

  • Page 104: Boot

    NANO-KBN-i1 5.5 Bo o t Use the Boot menu (BIOS Menu 17) to configure system boot options. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Boot Configuration Select the keyboard...
  • Page 105 NANO-KBN-i1  Qu ie t Bo o t [En a b le d ] Use the Quiet Boot BIOS option to select the screen display when the system boots.  Normal POST messages displayed Disabled  Enabled OEM Logo displayed instead of POST messages EFAULT ...

  • Page 106: Security

    NANO-KBN-i1 5.6 S e c u rity Use the Security menu (BIOS Menu 19) to set system and user passwords. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Password Description...

  • Page 107: Bios Menu 20: Exit

    NANO-KBN-i1 Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Save Changes and Reset Reset the system after Discard Changes and Reset saving the changes. Restore Defaults Save as User Defaults...

  • Page 108: A Bios Menu Options

    NANO-KBN-i1 Ap p e n d ix BIOS Me n u Op tio n s P a g e 94...
  • Page 109 NANO-KBN-i1  BIOS Information .........................67  iWDD Vendor ........................68  iWDD Version ........................68  System Date [xx/xx/xx] ......................68  System Time [xx:xx:xx] .......................68  ACPI Sleep State [S3 only (Suspend to RAM)] ..............69  Wake system with Fixed Time [Disabled] ................70 ...
  • Page 110 NANO-KBN-i1  Parity [None] .........................86  Stop Bits [1] ..........................87  HD Audio Azalia Device [Enabled] ..................88  Active LVDS1 [Disabled] .....................88  Power Saving Function (ERP) [Disabled] ................89  Bootup NumLock State [On] ....................90  Quiet Boot [Enabled] ......................91 ...

  • Page 111: B One Key Recovery

    NANO-KBN-i1 Ap p e n d ix On e Ke y Re c o ve ry P a g e 97...

  • Page 112: One Key Recovery Introduction

    NANO-KBN-i1 B.1 On e Ke y Re c o ve ry In tro d u c tio n The IEI one key recovery is an easy-to-use front end for the Norton Ghost system backup and recovery tool. This tool provides quick and easy shortcuts for creating a backup and reverting to that backup or reverting to the factory default settings.

  • Page 113: System Requirement

    NANO-KBN-i1 B.1.1 S ys te m Re q u ire m e n t NOTE: The recovery CD can only be used with IEI products. The software will fail to run and a warning message will appear when used on non-IEI hardware.

  • Page 114: Supported Operating System

    NANO-KBN-i1 NOTE: Specialized tools are required to change the partition size if the operating system is already installed. B.1.2 S u p p o rte d Op e ra tin g S ys te m The recovery CD is compatible with both Microsoft Windows and Linux operating systems (OS).

  • Page 115: Setup Procedure For Windows

    NANO-KBN-i1 NOTE: Installing unsupported OS versions may cause the recovery tool to fail. B.2 S e tu p P ro c e d u re fo r Win d ows Prior to using the recovery tool to backup or restore, a few setup procedures are required.

  • Page 116: Create Partitions

    NANO-KBN-i1 Press the <DELETE> key as soon as the system is turned on to enter the BIOS. S te p 5: boot device. (Boot  Boot Select the connected optical disk drive as the 1 S te p 6: Device Priority  1 Boot Device).

  • Page 117: Figure B-3: Recovery Tool Setup Menu

    NANO-KBN-i1 Figure B-3: Recovery Tool Setup Menu S te p 4: Press <6> then <Enter>. Figure B-4: Command Prompt The command prompt window appears. Type the following commands (marked S te p 5: in red) to create two partitions. One is for the OS installation; the other is for saving recovery files and images which will be an invisible partition.

  • Page 118: Figure B-5: Partition Creation Commands

    NANO-KBN-i1 system32>format N: /fs:ntfs /q /y system32>format F: /fs:ntfs /q /v:Recovery /y system32>exit Figure B-5: Partition Creation Commands P a g e 104...

  • Page 119: Install Operating System, Drivers And Applications

    NANO-KBN-i1 NOTE: Use the following commands to check if the partitions were created successfully. S te p 6: Press any key to exit the recovery tool and automatically reboot the system. Please continue to the following procedure: Build the Recovery Partition.S t e p 0 :...

  • Page 120: Building The Recovery Partition

    NANO-KBN-i1 B.2.4 Bu ild in g th e Re c o ve ry P a rtitio n Put the recover CD in the optical drive. S te p 1: Start the system. S te p 2: S te p 3: Boot the system from the recovery CD.

  • Page 121: Figure B-8: Building The Recovery Partition

    NANO-KBN-i1 S te p 5: The Symantec Ghost window appears and starts configuring the system to build a recovery partition. In this process the partition created for recovery files in Section B.2.2 is hidden and the recovery tool is saved in this partition.

  • Page 122: Create Factory Default Image

    NANO-KBN-i1 B.2.5 Cre a te Fa c to ry De fa u lt Im a g e NOTE: Before creating the factory default image, please configure the system to a factory default environment, including driver and application installations. To create a factory default image, please follow the steps below.

  • Page 123: Figure B-12: About Symantec Ghost Window

    NANO-KBN-i1 Figure B-12: About Symantec Ghost Window Use mouse to navigate to the option shown below (Figure B-13). S te p 4: Figure B-13: Symantec Ghost Path S te p 5: Select the local source drive (Drive 1) as shown in Figure B-14. Then click OK.

  • Page 124: Figure B-14: Select A Local Source Drive

    NANO-KBN-i1 Figure B-14: Select a Local Source Drive S te p 6: Select a source partition (Part 1) from basic drive as shown in Figure B-15. Then click OK. Figure B-15: Select a Source Partition from Basic Drive Select 1.2: [Recovery] NTFS drive and enter a file name called S te p 7: (Figure B-16).

  • Page 125: Figure B-16: File Name To Copy Image To

    NANO-KBN-i1 Figure B-16: File Name to Copy Image to When the Compress Image screen in Figure B-17 prompts, click High to make S te p 8: the image file smaller. Figure B-17: Compress Image P a g e 111...

  • Page 126: Figure B-18: Image Creation Confirmation

    NANO-KBN-i1 The Proceed with partition image creation window appears, click Yes to S te p 9: continue. Figure B-18: Image Creation Confirmation The Symantec Ghost starts to create the factory default image (Figure B-19). S te p 10: Figure B-19: Image Creation Complete When the image creation completes, a screen prompts as shown in Figure B-20.

  • Page 127: Setup Procedure For Linux

    NANO-KBN-i1 S te p 12: The recovery tool main menu window is shown as below. Press any key to reboot the system. S t e p 0 : Figure B-21: Press Any Key to Continue B.3 S e tu p P ro c e d u re fo r Lin u x The initial setup procedure for Linux system is mostly the same with the procedure for Microsoft Windows.

  • Page 128: Figure B-22: Partitions For Linux

    NANO-KBN-i1 NOTE: Please reserve enough space for partition 3 for saving recovery images. Figure B-22: Partitions for Linux S te p 3: Create a recovery partition. Insert the recovery CD into the optical disk drive. Follow Step 1 Step 3 described in Section B.2.2.

  • Page 129: Figure B-23: Manual Recovery Environment For Linux

    NANO-KBN-i1 Figure B-23: Manual Recovery Environment for Linux S te p 5: Access the recovery tool main menu by modifying the “menu.lst”. To first access the recovery tool main menu, the menu.lst must be modified. In Linux, enter Administrator (root). When prompt appears, type: cd /boot/grub vi menu.lst...

  • Page 130: Recovery Tool Functions

    NANO-KBN-i1 S te p 7: The recovery tool menu appears. (Figure B-25) Figure B-25: Recovery Tool Menu Create a factory default image. Follow Step 2 Step 12 described in Section S te p 8: B.2.5 to create a factory default image.

  • Page 131: Figure B-26: Recovery Tool Main Menu

    NANO-KBN-i1 Figure B-26: Recovery Tool Main Menu The recovery tool has several functions including: 1. Factory Restore: Restore the factory default image (iei.GHO) created in Section B.2.5. 2. Backup system: Create a system backup image (iei_user.GHO) which will be saved in the hidden partition.

  • Page 132: Factory Restore

    NANO-KBN-i1 B.4.1 Fa c to ry Re s to re To restore the factory default image, please follow the steps below. S te p 1: Type <1> and press <Enter> in the main menu. S te p 2: The Symantec Ghost window appears and starts to restore the factory default. A factory default image called iei.GHO is created in the hidden Recovery partition.

  • Page 133: Backup System

    NANO-KBN-i1 B.4.2 Ba c ku p S ys te m To backup the system, please follow the steps below. S te p 1: Type <2> and press <Enter> in the main menu. S te p 2: The Symantec Ghost window appears and starts to backup the system. A backup image called iei_user.GHO is created in the hidden Recovery partition.

  • Page 134: Restore Your Last Backup

    NANO-KBN-i1 B.4.3 Re s to re Yo u r La s t Ba c ku p To restore the last system backup, please follow the steps below. S te p 1: Type <3> and press <Enter> in the main menu.

  • Page 135: Manual

    NANO-KBN-i1 B.4.4 Ma n u a l To restore the last system backup, please follow the steps below. S te p 4: Type <4> and press <Enter> in the main menu. S te p 5: The Symantec Ghost window appears. Use the Ghost program to backup or recover the system manually.

  • Page 136: Restore Systems From A Linux Server Through Lan

    NANO-KBN-i1 B.5 Re s to re S ys te m s fro m a Lin u x S e rve r thro u g h LAN The One Key Recovery allows a client system to automatically restore to a factory default image saved in a Linux system (the server) through LAN connectivity after encountering a Blue Screen of Death (BSoD) or a hang for around 10 minutes.

  • Page 137: Configure Dhcp Server Settings

    NANO-KBN-i1 B.5.1 Co n fig u re DHCP S e rve r S e ttin g s Install the DHCP S te p 1: #yum install dhcp (CentOS, commands marked in red) #apt-get install dhcp3-server (Debian, commands marked in blue) Confirm the operating system default settings: dhcpd.conf.

  • Page 138: Configure Tftp Settings

    NANO-KBN-i1 filename “pxelinux.0”; B.5.2 Co n fig u re TFTP S e ttin g s S te p 1: Install the tftp, httpd and syslinux. #yum install tftp-server httpd syslinux (CentOS) #apt-get install tftpd-hpa xinetd syslinux (Debian) S te p 2: Enable the TFTP server by editing the “/etc/xinetd.d/tftp”...

  • Page 139: Configure One Key Recovery Server Settings

    NANO-KBN-i1 Debian Replace the TFTP settings from “inetd” to “xinetd” and annotate the “inetd” by adding “#”. #vi /etc/inetd.conf Modify: #tftp dgram udp wait root /usr/sbin..(as shown below) #vi /etc/xinetd.d/tftp B.5.3 Co n fig u re On e Ke y Re c o ve ry S e rve r S e ttin g s Copy the Utility/RECOVERYR10.TAR.BZ2 package from the One Key...

  • Page 140: Start The Dhcp, Tftp And Http

    NANO-KBN-i1 B.5.4 Sta rt th e DHCP, TFTP a n d HTTP Start the DHCP, TFTP and HTTP. For example: CentOS #service xinetd restart #service httpd restart #service dhcpd restart Debian #/etc/init.d/xinetd reload #/etc/init.d/xinetd restart #/etc/init.d/dhcp3-server restart B.5.5 Cre a te S ha re d Dire c to ry S te p 1: Install the samba.

  • Page 141: Setup A Client System For Auto Recovery

    NANO-KBN-i1 Modify: [image] comment = One Key Recovery path = /share/image browseable = yes writable = yes public = yes create mask = 0644 directory mask = 0755 S te p 4: Edit “/etc/samba/smb.conf” for your environment. For example: Modify the hostname...
  • Page 142 NANO-KBN-i1 Continue to configure the Boot Option Priorities BIOS option of the client S te p 2: system: Boot Option #1  remain the default setting to boot from the original OS. Boot Option #2  select the boot from LAN option.
  • Page 143 NANO-KBN-i1 NOTE: A firewall or a SELinux is not in use in the whole setup process. If there is a firewall or a SELinux protecting the system, modify the configuration information to accommodate them. P a g e 129...

  • Page 144: Other Information

    NANO-KBN-i1 B.6 Oth e r In fo rm a tio n B.6.1 Us in g AHCI Mo d e o r ALi M5283 / VIA VT6421A Co n tro lle r When the system uses AHCI mode or some specific SATA controllers such as ALi M5283 or VIA VT6421A, the SATA RAID/AHCI driver must be installed before using one key recovery.
  • Page 145 NANO-KBN-i1 When the following window appears, press <S> to select “Specify Additional S te p 5: Device”. In the following window, select a SATA controller mode used in the system. Then S te p 6: press <Enter>. The user can now start using the SATA HDD.

  • Page 146: System Memory Requirement

    NANO-KBN-i1 S te p 7: After pressing <Enter>, the system will get into the recovery tool setup menu. Continue to follow the setup procedure from Step 4 in Section B.2.2 Create Partitions to finish the whole setup process. S t e p 0 : B.6.2 S ys te m Me m o ry Re q u ire m e n t...

  • Page 147: C Terminology

    NANO-KBN-i1 Ap p e n d ix Te rm in o lo g y P a g e 133...
  • Page 148 NANO-KBN-i1 AC ’97 Audio Codec 97 (AC’97) refers to a codec standard developed by Intel® in 1997. ACPI Advanced Configuration and Power Interface (ACPI) is an OS-directed configuration, power management, and thermal management interface. AHCI Advanced Host Controller Interface (AHCI) is a SATA Host controller register-level interface.
  • Page 149 NANO-KBN-i1 computer is usually a male DE-9 connector. The Digital-to-Analog Converter (DAC) converts digital signals to analog signals. Double Data Rate refers to a data bus transferring data on both the rising and falling edges of the clock signal. Direct Memory Access (DMA) enables some peripheral devices to bypass the system processor and communicate directly with the system memory.
  • Page 150 NANO-KBN-i1 PCIe PCI Express (PCIe) is a communications bus that uses dual data lines for full-duplex (two-way) serial (point-to-point) communications between the SBC components and/or expansion cards and the SBC chipsets. Each line has a 2.5 Gbps data transmission rate and a 250 MBps sustained data transfer rate.
  • Page 151 NANO-KBN-i1 USB 2.0 supports 480Mbps data transfer rates. The Video Graphics Array (VGA) is a graphics display system developed by IBM. P a g e 137...

  • Page 152: D Watchdog Timer

    NANO-KBN-i1 Ap p e n d ix Wa tc h d o g Tim e r P a g e 138...
  • Page 153 NANO-KBN-i1 NOTE: The following discussion applies to DOS environment. IEI support is contacted or the IEI website visited for specific drivers for more sophisticated operating systems, e.g., Windows and Linux. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash.
  • Page 154 NANO-KBN-i1 NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. Example program: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30H ;time-out value is 48 seconds ; ADD THE APPLICATION PROGRAM HERE EXIT_AP, 1 ;is the application over?

  • Page 155: E Hazardous Materials Disclosure

    NANO-KBN-i1 Ap p e n d ix Ha za rd o u s Ma te ria ls Dis c lo s u re P a g e 141...
  • Page 156 NANO-KBN-i1 E.1 Ha za rd o u s Ma te ria l Dis c lo s ure Ta b le fo r IP B P ro d u c ts Ce rtifie d a s Ro HS Co m p lia n t Un d e r 2002/95/EC With o u t...
  • Page 157 NANO-KBN-i1 Part Name Toxic or Hazardous Substances and Elements Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated (Pb) (Hg) (Cd) Chromium Biphenyls Diphenyl Ethers (CR(VI)) (PBB) (PBDE) Housing Display Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Power Supply Assemblies Battery...
  • Page 158 NANO-KBN-i1 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本 产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11363-2006 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11363-2006 标准规定的限量要求。...

Table of Contents
