NANO-BT-i1 EPIC SBC
MODEL:
NANO-BT-i1 Series
EPIC SBC with 22nm Intel® Atom™ or Celeron® SoC,
Dual GbE, DDR3, HDMI, VGA, LVDS, USB 2.0/3.0, COM Ports
Two SATA 3Gb/s Ports, IPMI 2.0 and RoHS

User Manual

Page i
Rev. 1.03 – October 1, 2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NANO-BT-i1 Series and is the answer not in the manual?

Questions and answers

Related Manuals for IEI Technology NANO-BT-i1 Series

Summary of Contents for IEI Technology NANO-BT-i1 Series

  • Page 1: User Manual

    NANO-BT-i1 EPIC SBC MODEL: NANO-BT-i1 Series EPIC SBC with 22nm Intel® Atom™ or Celeron® SoC, Dual GbE, DDR3, HDMI, VGA, LVDS, USB 2.0/3.0, COM Ports Two SATA 3Gb/s Ports, IPMI 2.0 and RoHS User Manual Page i Rev. 1.03 – October 1, 2014...
  • Page 2 NANO-BT-i1 EPIC SBC Revision Date Version Changes October 1, 2014 1.03 Updated Section 1.6: Dimensions June 27, 2014 1.02 Updated supported memory specifications in Chapter 1. May 7, 2014 1.01 Updated Section 1.6: Dimensions Updated Chapter 6: Software Drivers Updated Table 3-15: LVDS Connector Pinouts April 3, 2014 1.00 Initial release...
  • Page 3 NANO-BT-i1 EPIC SBC Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 4: Table Of Contents

    NANO-BT-i1 EPIC SBC Table of Contents 1 INTRODUCTION......................1 1.1 I ......................2 NTRODUCTION 1.2 M ....................3 ODEL ARIATIONS 1.3 B ........................3 ENEFITS 1.4 F ........................4 EATURES 1.5 C ......................5 ONNECTORS 1.6 D ....................... 7 IMENSIONS 1.7 D ........................
  • Page 5 NANO-BT-i1 EPIC SBC 3.2.10 Front Panel Connector .................. 28 3.2.11 IPMI LED Connector ..................29 3.2.12 iRIS Module Slot .................... 30 3.2.13 LAN LED Connectors ..................31 3.2.14 LVDS Connector .................... 32 3.2.15 Memory Card Slot ..................33 3.2.16 PCI-104 Connector..................34 3.2.17 PCIe Mini Card Slot ..................
  • Page 6 NANO-BT-i1 EPIC SBC 4.3.2 Clear CMOS Button..................59 4.3.3 LVDS Panel Resolution Selection ..............60 4.3.4 LCD Voltage Selection ..................61 4.3.5 mSATA/SATA Selection..................62 4.3.6 PCI-104 Voltage Selection ................63 4.4 I ............63 NTERNAL ERIPHERAL EVICE ONNECTIONS 4.4.1 AT Power Connection ..................63 4.4.2 SATA Drive Connection ...................
  • Page 7 NANO-BT-i1 EPIC SBC 5.3.7 CPU Configuration ..................93 5.3.8 IDE Configuration ................... 96 5.3.9 USB Configuration................... 97 5.4 C ........................98 HIPSET 5.4.1 North Bridge ....................99 5.4.1.1 Intel IGD Configuration................100 5.4.2 South Bridge....................101 5.4.2.1 PCI Express Configuration ..............103 5.5 S .......................
  • Page 8 NANO-BT-i1 EPIC SBC List of Figures Figure 1-1: NANO-BT-i1 .........................2 Figure 1-2: Connectors (Front Side) .....................5 Figure 1-3: Connectors (Solder Side) ...................6 Figure 1-4: NANO-BT-i1 Main Dimensions (mm).................7 Figure 1-5: NANO-BT-i1 Height Dimensions 1 (mm)..............8 Figure 1-6: NANO-BT-i1 Height Dimensions 2 (mm)..............8 Figure 1-7: Data Flow Diagram......................9 Figure 3-1: Connectors and Jumpers (Front Side) ..............17 Figure 3-2: Connectors and Jumpers (Solder Side) ..............18...
  • Page 9 NANO-BT-i1 EPIC SBC Figure 3-24: SATA Power Connector Locations ...............41 Figure 3-25: RS-232 Serial Port Connector Locations..............42 Figure 3-26: RS-422/485 Connector Location................43 Figure 3-27: SMBus Connector Location ...................44 Figure 3-28: SPI Flash Connector Location................45 Figure 3-29: SPI EC Flash Connector Location.................46 Figure 3-30: USB 2.0 Connector Location .................47 Figure 3-31: External Peripheral Interface Connector ..............47 Figure 3-32: Ethernet Connector....................49...
  • Page 10 NANO-BT-i1 EPIC SBC Figure 6-7: Chipset Driver Installation Finish Screen............114 Figure 6-8: Graphics Driver Welcome Screen ................ 116 Figure 6-9: Graphics Driver License Agreement..............116 Figure 6-10: Graphics Driver Read Me File ................117 Figure 6-11: Graphics Driver Setup Operations ..............117 Figure 6-12: Graphics Driver Installation Finish Screen ............
  • Page 11 NANO-BT-i1 EPIC SBC List of Tables Table 1-1: Model Variations ......................3 Table 1-2: NANO-BT-i1 Specifications..................11 Table 2-1: Packing List.........................15 Table 2-2: Optional Items......................15 Table 3-1: Peripheral Interface Connectors ................19 Table 3-2: Rear Panel Connectors ....................20 Table 3-3: CPU Power Connector Pinouts .................21 Table 3-4: Audio Connector Pinouts ..................22 Table 3-5: Battery Connector Pinouts ..................23 Table 3-6: Backlight Inverter Connector Pinouts ..............24...
  • Page 12 NANO-BT-i1 EPIC SBC Table 3-27: SPI EC Flash Connector Pinouts ................46 Table 3-28: USB 2.0 Connector Pinouts ..................47 Table 3-29: LAN1 Ethernet Connector Pinouts .................48 Table 3-30: LAN2 Ethernet Connector Pinouts .................48 Table 3-31: Connector LEDs......................49 Table 3-32: HDMI Connector Pinouts ..................50 Table 3-33: Keyboard Connector Pinouts..................51 Table 3-34: USB 2.0 Port Pinouts....................51 Table 3-35: USB 3.0 Port Pinouts....................52...
  • Page 13 NANO-BT-i1 EPIC SBC BIOS Menus BIOS Menu 1: Main ........................76 BIOS Menu 2: Advanced ......................77 BIOS Menu 3: ACPI Configuration ....................78 BIOS Menu 4: Super IO Configuration..................79 BIOS Menu 5: Serial Port n Configuration Menu...............79 BIOS Menu 6: Hardware Monitor....................85 BIOS Menu 7: Smart Fan Mode Configuration ................86 BIOS Menu 8: iWDD H/W Monitor....................88 BIOS Menu 9: Smart Fan Mode Configuration ................89...

  • Page 15: Introduction

    NANO-BT-i1 EPIC SBC Chapter Introduction Page 1...

  • Page 16: Introduction

    NANO-BT-i1 EPIC SBC 1.1 Introduction Figure 1-1: NANO-BT-i1 The NANO-BT-i1 is an EPIC form factor single bard computer. It has an on-board 22nm Intel® Atom™ or Celeron® processor, and supports one 204-pin 1333/1066 MHz dual-channel unbuffered DDR3 Low Voltage (DDR3L) SDRAM SO-DIMM with up to 8.0 GB of memory.

  • Page 17: Model Variations

    NANO-BT-i1 EPIC SBC 1.2 Model Variations There are eight models of the NANO-BT-i1 series. The model variations are listed in Table 1-1. Model On-board SoC Max. Memory Size NANO-BT-i1-E38151 Intel® Atom™ processor E3815 4 GB (1.46 GHz, single-core, 512 KB cache) NANO-BT-i1-E38251 Intel®...

  • Page 18: Features

    NANO-BT-i1 EPIC SBC 1.4 Features Some of the NANO-BT-i1 motherboard features are listed below:  EPIC form factor  RoHS compliant  On-board 22nm Intel® Atom™ or Celeron® processor  One 204-pin 1333/1066 MHz dual-channel unbuffered DDR3L (1.35 V) SDRAM SO-DIMM slot supports up to 8.0 GB of memory ...

  • Page 19: Connectors

    NANO-BT-i1 EPIC SBC 1.5 Connectors The connectors on the NANO-BT-i1 are shown in the figure below. Figure 1-2: Connectors (Front Side) Page 5...

  • Page 20: Figure 1-3: Connectors (Solder Side)

    NANO-BT-i1 EPIC SBC Figure 1-3: Connectors (Solder Side) Page 6...

  • Page 21: Dimensions

    NANO-BT-i1 EPIC SBC 1.6 Dimensions The main dimensions of the NANO-BT-i1 are shown in the diagram below. Figure 1-4: NANO-BT-i1 Main Dimensions (mm) Page 7...

  • Page 22: Figure 1-5: Nano-Bt-I1 Height Dimensions 1 (Mm)

    NANO-BT-i1 EPIC SBC The height of the NANO-BT-i1 series varies depending on the heatsink installed on the board. Figure 1-5 shows the height dimensions of the following models:  NANO-BT-i1-E38271  NANO-BT-i1-E38261  NANO-BT-i1-E38251  NANO-BT-i1-E38151  NANO-BT-i1-N28071 Figure 1-5: NANO-BT-i1 Height Dimensions 1 (mm) Figure 1-6 shows the height dimensions of the following models: ...

  • Page 23: Data Flow

    NANO-BT-i1 EPIC SBC 1.7 Data Flow F igure 1-7 shows the data flow between the system chipset, the CPU and other components installed on the motherboard. Figure 1-7: Data Flow Diagram Page 9...

  • Page 24: Technical Specifications

    NANO-BT-i1 EPIC SBC 1.8 Technical Specifications NANO-BT-i1 technical specifications are listed below. Specification/Model NANO-BT-i1 EPIC Form Factor Intel® Atom™ processor E3845 (1.91GHz, quad-core, 2MB cache, TDP=10W) On-board SoC Intel® Atom™ processor E3827 (1.75GHz, dual-core, 1MB cache, TDP=8W) Intel® Atom™ processor E3826 (1.46GHz, dual-core, 1MB cache, TDP=7W) Intel®...

  • Page 25: Table 1-2: Nano-Bt-I1 Specifications

    NANO-BT-i1 EPIC SBC Specification/Model NANO-BT-i1 One PCIe Mini card slot PCIe I/O Interface Connectors Audio Connector One internal audio connector (10-pin) Display Ports One VGA port (up to 2560 x 1600, 60Hz) One HDMI port (up to 2560 x 1600, 60Hz) 18-bit/24-bit dual-channel LVDS (up to 1920 x 1200, 60Hz) Ethernet Two RJ-45 GbE ports...

  • Page 26: Packing List

    NANO-BT-i1 EPIC SBC Chapter Packing List Page 12...

  • Page 27: Anti-Static Precautions

    NANO-BT-i1 EPIC SBC 2.1 Anti-static Precautions WARNING! Static electricity can destroy certain electronics. Make sure to follow the ESD precautions to prevent damage to the product, and injury to the user. Make sure to adhere to the following guidelines:  Wear an anti-static wristband: Wearing an anti-static wristband can prevent electrostatic discharge.

  • Page 28: Packing List

    NANO-BT-i1 EPIC SBC 2.3 Packing List NOTE: If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the NANO-BT-i1 was purchased from or contact sales representative directly by sending an email to s ales@ieiworld.com The NANO-BT-i1 is shipped with the following components: Quantity...

  • Page 29: Optional Items

    NANO-BT-i1 EPIC SBC Quantity Item and Part Number Image One Key Recovery CD Quick Installation Guide Table 2-1: Packing List 2.4 Optional Items The following are optional components which may be separately purchased: Item and Part Number Image IPMI 2.0 adapter card with AST1010 BMC chip (without KVM over IP function) for PCIe Mini socket interface (P/N: iRIS-1010-R10) Dual USB cable...

  • Page 30: Connectors

    NANO-BT-i1 EPIC SBC Chapter Connectors Page 16...

  • Page 31: Peripheral Interface Connectors

    NANO-BT-i1 EPIC SBC 3.1 Peripheral Interface Connectors This chapter details all the jumpers and connectors. 3.1.1 NANO-BT-i1 Layout The figures below show all the connectors and jumpers. Figure 3-1: Connectors and Jumpers (Front Side) Page 17...

  • Page 32: Peripheral Interface Connectors

    NANO-BT-i1 EPIC SBC Figure 3-2: Connectors and Jumpers (Solder Side) 3.1.2 Peripheral Interface Connectors The table below lists all the connectors on the board. Connector Type Label 12 V DC input connector 4-pin connector CN10 Audio connector 10-pin header AUDIO1 Battery connector 2-pin wafer BAT1...

  • Page 33: Table 3-1: Peripheral Interface Connectors

    NANO-BT-i1 EPIC SBC Connector Type Label Fan connector (system) 3-pin wafer SYS_FAN1 Front panel connector 6-pin wafer CN11 iRIS module connector Half-size PCIe Mini slot IPMI1 IPMI LED connector 2-pin header ID_LED2 LAN1 LED connector 2-pin header LAN2 LED connector 2-pin header LVDS connector 30-pin crimp...

  • Page 34: External Interface Panel Connectors

    NANO-BT-i1 EPIC SBC 3.1.3 External Interface Panel Connectors The table below lists the connectors on the external I/O panel. Connector Type Label Ethernet ports RJ-45 LAN1, LAN2 HDMI connector HDMI CN12 Keyboard/Mouse connector PS/2 USB 2.0 connector USB 2.0 USB 3.0 connector USB 3.0 VGA connector 15-pin female...

  • Page 35: Audio Connector

    NANO-BT-i1 EPIC SBC Figure 3-3: CPU Power Connector Location PIN NO. DESCRIPTION +12 V +12 V Table 3-3: CPU Power Connector Pinouts 3.2.2 Audio Connector CN Label: AUDIO1 10-pin header CN Type: CN Location: See Figure 3-4 CN Pinouts: See Table 3-4 This connector connects to speakers, a microphone and an audio input.

  • Page 36: Battery Connector

    NANO-BT-i1 EPIC SBC Figure 3-4: Audio Connector Location Description Description LINE_OUTR LINEIN_R ANALOG_GND ANALOG_GND LINE_OUTL LINEIN_L ANALOG_GND ANALOG_GND MICIN1 MICIN2 Table 3-4: Audio Connector Pinouts 3.2.3 Battery Connector CAUTION: Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery.

  • Page 37: Backlight Inverter Connector

    NANO-BT-i1 EPIC SBC A system battery is placed in the battery holder. The battery provides power to the system clock to retain the time when power is turned off. Figure 3-5: Battery Connector Location Description VBATT Table 3-5: Battery Connector Pinouts 3.2.4 Backlight Inverter Connector CN Label: INV1...

  • Page 38: Buzzer Connector

    NANO-BT-i1 EPIC SBC Description BRIGHTNESS2 ENABKL2 Table 3-6: Backlight Inverter Connector Pinouts 3.2.5 Buzzer Connector CN Label: 2-pin wafer CN Type: CN Location: See Figure 3-7 The connector is connected to a buzzer. Figure 3-7: Buzzer Connector Location Page 24...

  • Page 39: Chassis Intrusion Connector

    NANO-BT-i1 EPIC SBC 3.2.6 Chassis Intrusion Connector CN Label: CHASSIS1 2-pin header CN Type: CN Location: F igure 3-8 CN Pinouts: See Table 3-7 The chassis intrusion connector is for a chassis intrusion detection sensor or switch that detects if a chassis component is removed or replaced. Figure 3-8: Chassis Intrusion Connector Location Description +V3.3A_EC...

  • Page 40: Fan Connector (Cpu)

    NANO-BT-i1 EPIC SBC Figure 3-9: Digital I/O Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION DOUT3 DOUT2 DOUT1 DOUT0 DIN3 DIN2 DIN1 DIN0 Table 3-8: Digital I/O Connector Pinouts 3.2.8 Fan Connector (CPU) CN Label: CPU_FAN1 CN Type: 3-pin wafer See Figure 3-10 CN Location: CN Pinouts:...

  • Page 41: Fan Connector (System)

    NANO-BT-i1 EPIC SBC Figure 3-10: CPU Fan Connector Location PIN NO. DESCRIPTION FAN_IN VCC (+12 V) Table 3-9: CPU Fan Connector Pinouts 3.2.9 Fan Connector (System) CN Label: SYS_FAN1 3-pin wafer CN Type: CN Location: See Figure 3-11 CN Pinouts: See Table 3-10 Each fan connector attaches to a system cooling fan.

  • Page 42: Front Panel Connector

    NANO-BT-i1 EPIC SBC Figure 3-11: System Fan Connector Location PIN NO. DESCRIPTION FAN_IN VCC (+12 V) Table 3-10: System Fan Connector Pinouts 3.2.10 Front Panel Connector CN Label: CN11 6-pin wafer CN Type: CN Location: See Figure 3-12 CN Pinouts: See Table 3-11 The front panel connector connects to the indicator LEDs on the computer's front panel.

  • Page 43: Ipmi Led Connector

    NANO-BT-i1 EPIC SBC Figure 3-12: Front Panel Connector Location DESCRIPTION DESCRIPTION PWR_LED- HDD_LED+ PWR_LED+ HDD_LED- Table 3-11: Front Panel Connector Pinouts 3.2.11 IPMI LED Connector CN Label: ID_LED2 CN Type: 2-pin header CN Location: See Figure 3-13 See Table 3-12 CN Pinouts: The IPMI LED connector is used to connect to the IPMI LED indicator on the chassis.

  • Page 44: Iris Module Slot

    NANO-BT-i1 EPIC SBC Figure 3-13: IPMI LED Connector Location Description ID_LED+ ID_LED- Table 3-12: IPMI LED Connector Pinouts 3.2.12 iRIS Module Slot CN Label: IPMI1 CN Type: Half-size PCIe Mini slot CN Location: F igure 3-14 The iRIS module slot is used to install the IEI iRIS-1010 IPMI 2.0 module. WARNING: The iRIS module slot is designed to install the IEI iRIS-1010 IPMI 2.0 module only.

  • Page 45: Lan Led Connectors

    NANO-BT-i1 EPIC SBC Figure 3-14: iRIS Module Slot Location 3.2.13 LAN LED Connectors CN Label: JP8, JP9 CN Type: 2-pin header CN Location: F igure 3-15 CN Pinouts: T able 3-13 and Table 3-14 The LAN LED connectors are used to connect to the LAN LED indicators on the chassis to indicate users the link activities of the two LAN ports.

  • Page 46: Lvds Connector

    NANO-BT-i1 EPIC SBC Description L2_LINK_ACT- Table 3-14: LAN2 LED Connector (JP9) Pinouts 3.2.14 LVDS Connector CN Label: CN Type: 30-pin crimp CN Location: See Figure 3-16 See Table 3-15 CN Pinouts: The LVDS connector is for an LCD panel connected to the board. Figure 3-16: LVDS Connector Location Description Description...

  • Page 47: Memory Card Slot

    NANO-BT-i1 EPIC SBC Description Description LVDS_ A_TX3-P LVDS_ A_TX3-N LVDS_B_TX0-P LVDS_ B_TX0-N LVDS_ B_TX1-P LVDS_ B_TX1-N LVDS_ B_TX2-P LVDS_ B_TX2-N LVDS_ B_TXCLK-P LVDS_ B_TXCLK-N LVDS_ B_TX3-P LVDS_ B_TX3-N +LCD VCC +LCD VCC +LCD VCC +LCD VCC Table 3-15: LVDS Connector Pinouts 3.2.15 Memory Card Slot CN Label: DIMM1...

  • Page 48: Connector

    NANO-BT-i1 EPIC SBC 3.2.16 PCI-104 Connector CN Label: PC104_PLUS1 PCI-104 connector CN Type: CN Location: See Figure 3-18 CN Pinouts: See Table 3-16 The PCI-104 connector is for installing a PCI-104 expansion card. Figure 3-18: PCI-104 Connector Location Row A Row B Row C Row D...

  • Page 49: Pcie Mini Card Slot

    NANO-BT-i1 EPIC SBC Row A Row B Row C Row D FRAME# IRDY# +3.3 V AD16 +3.3 V C/BE2# AD18 +3.3 V AD17 AD21 AD20 AD19 +3.3 V AD23 AD22 +3.3 V IDSEL0 IDSEL1 IDSEL2 AD24 C/BE3# VI/O1 IDSEL3 AD26 AD25 AD29 +5 V...

  • Page 50: Figure 3-19: Pcie Mini Card Slot Location

    NANO-BT-i1 EPIC SBC Figure 3-19: PCIe Mini Card Slot Location Description Description PCIE_WAKE# VCC3 1.5 V VCC3 CLK- CLK+ BUF_PLT_RST# VCC3 BUF_PLT_RST# PCIE_RX4DN_M VCC3 PCIE_RX4DP_M 1.5 V SMBCLK PCIE_TX4DN_CM SMBDATA PCIE_TX4DP_CM USBD3- USBD3+ VCC3 VCC3 RF_LINK# Page 36...

  • Page 51: Power Button Connector

    NANO-BT-i1 EPIC SBC Description Description BLUELED# 1.5 V M-SATADET VCC3 Table 3-17: PCIe Mini Card Slot Pinouts 3.2.18 Power Button Connector CN Label: PWR_BTN1 2-pin wafer CN Type: CN Location: See Figure 3-20 CN Pinouts: See Table 3-18 The power button connector is connected to a power switch on the system chassis. Figure 3-20: Power Button Location Description PWRBTN_SW#...

  • Page 52: Power Button

    NANO-BT-i1 EPIC SBC 3.2.19 Power Button CN Label: PWR_SW1 Push button CN Type: CN Location: See Figure 3-21 The on-board power button controls system power. Figure 3-21: Power Button Location 3.2.20 Reset Button Connector CN Label: RST_BTN1 CN Type: 2-pin wafer CN Location: See Figure 3-22 See Table 3-19...

  • Page 53: Sata 3Gb/S Drive Connectors

    NANO-BT-i1 EPIC SBC Figure 3-22: Reset Button Connector Location Description PM_SYSRST_R# Table 3-19: Reset Button Connector Pinouts 3.2.21 SATA 3Gb/s Drive Connectors CN Label: SATA1, SATA2 CN Type: 7-pin SATA drive connectors CN Location: See Figure 3-23 CN Pinouts: See Table 3-20 The SATA drive connectors can be connected to SATA drives.

  • Page 54: Sata Power Connectors

    NANO-BT-i1 EPIC SBC Figure 3-23: SATA 3Gb/s Drive Connector Locations Description SATA_TX+ SATA_TX- SATA_RX- SATA_RX+ Table 3-20: SATA 3Gb/s Drive Connector Pinouts 3.2.22 SATA Power Connectors CN Label: SATA_PWR1, SATA_PWR2 CN Type: 2-pin wafer CN Location: See Figure 3-24 CN Pinouts: See Table 3-21 Use the SATA Power Connector to connect to SATA device power connections.

  • Page 55: Serial Port Connectors, Rs-232

    NANO-BT-i1 EPIC SBC Figure 3-24: SATA Power Connector Locations Description +5VS Table 3-21: SATA Power Connector Pinouts 3.2.23 Serial Port Connectors, RS-232 CN Label: COM1, COM2, COM3 CN Type: 10-pin header CN Location: See Figure 3-25 CN Pinouts: See Table 3-22 The connector provides RS-232 port connection.

  • Page 56: Serial Port Connector, Rs-422/485

    NANO-BT-i1 EPIC SBC Figure 3-25: RS-232 Serial Port Connector Locations PIN NO. DESCRIPTION PIN NO. DESCRIPTION SOUT Table 3-22: RS-232 Serial Port Connector Pinouts 3.2.24 Serial Port Connector, RS-422/485 CN Label: COM4 CN Type: 4-pin wafer CN Location: See Figure 3-26 CN Pinouts: See Table 3-23 Used for RS-422/485 communications.

  • Page 57: Smbus Connector

    NANO-BT-i1 EPIC SBC Figure 3-26: RS-422/485 Connector Location PIN NO. DESCRIPTION RXD422- RXD422+ TXD422+/TXD485+ TXD422-/TXD485- Table 3-23: RS-422/485 Connector Pinouts Use the optional RS-422/485 cable to connect to a serial device. The pinouts of the D-sub 9 connector are listed below. RS-422 Pinouts RS-485 Pinouts Table 3-24: RS-422/485 Pinouts of D-sub 9 Connector...

  • Page 58: Spi Flash Connector

    NANO-BT-i1 EPIC SBC The SMBus (System Management Bus) connector provides low-speed system management communications. Figure 3-27: SMBus Connector Location DESCRIPTION SMB_DATA SMB_CLK +5 V Table 3-25: SMBus Connector Pinouts 3.2.26 SPI Flash Connector CN Label: JSPI1 CN Type: 6-pin wafer CN Location: See Figure 3-28 CN Pinouts:...

  • Page 59: Spi Flash Connector, Ec

    NANO-BT-i1 EPIC SBC Figure 3-28: SPI Flash Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION +1.8 VA SPI_CLK_SW SPI_CS SPI_SI_SW SPI_SO_SW Table 3-26: SPI Flash Connector Pinouts 3.2.27 SPI Flash Connector, EC CN Label: JSPI2 6-pin wafer CN Type: CN Location: See Figure 3-29 CN Pinouts: See Table 3-27...

  • Page 60: Usb 2.0 Connector

    NANO-BT-i1 EPIC SBC Figure 3-29: SPI EC Flash Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3 A SPI_CLK_SW_EC SPI_CS#0_CN_EC SPI_SI_SW_EC SPI_SO_SW_EC Table 3-27: SPI EC Flash Connector Pinouts 3.2.28 USB 2.0 Connector CN Label: USB1 8-pin header CN Type: CN Location: See Figure 3-30 CN Pinouts:...

  • Page 61: External Peripheral Interface Connector Panel

    NANO-BT-i1 EPIC SBC Figure 3-30: USB 2.0 Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION +VCC_USB45 DATA4- DATA5+ DATA4+ DATA5- +VCC_USB45 Table 3-28: USB 2.0 Connector Pinouts 3.3 External Peripheral Interface Connector Panel The figure below shows the external peripheral interface connector (EPIC) panel. The EPIC panel consists of the following: Figure 3-31: External Peripheral Interface Connector 3.3.1 Ethernet Connectors...

  • Page 62: Table 3-29: Lan1 Ethernet Connector Pinouts

    NANO-BT-i1 EPIC SBC CN Location: See Figure 3-31 CN Pinouts: See Table 3-29 and Table 3-30 A 10/100/1000 Mb/s connection can be made to a Local Area Network. The LAN1 Ethernet connector supports IPMI 2.0. Description Description IO_GND TRD1N0 IO_GND TRD1P1 L1_100- TRD1N1...

  • Page 63: Hdmi Connector

    NANO-BT-i1 EPIC SBC Figure 3-32: Ethernet Connector Description Description on: linked off: 10 Mb/s blinking: data is being sent/received green: 100 Mb/s orange: 1000 Mb/s Table 3-31: Connector LEDs 3.3.2 HDMI Connector CN Label: CN12 23-pin HDMI port CN Type: CN Location: See Figure 3-31 CN Pinouts:...

  • Page 64: Keyboard/Mouse Connector

    NANO-BT-i1 EPIC SBC Description Description HDMI_GND HDMI_GND HDMI_GND Table 3-32: HDMI Connector Pinouts Figure 3-33: HDMI Connector 3.3.3 Keyboard/Mouse Connector CN Label: PS/2 CN Type: CN Location: See Figure 3-31 CN Pinouts: See Table 3-33 The keyboard and mouse connector is a standard PS/2 connector. Figure 3-34: PS/2 Pinout and Configuration Description KB DATA...

  • Page 65: Usb 2.0 Connector

    NANO-BT-i1 EPIC SBC Description MS CLOCK Table 3-33: Keyboard Connector Pinouts 3.3.4 USB 2.0 Connector CN Label: CN Type: USB 2.0 port CN Location: See Figure 3-31 CN Pinouts: See Table 3-34 The USB connector can be connected to a USB device. Description Description USB3_PWR1...

  • Page 66: Vga Connector

    NANO-BT-i1 EPIC SBC Description Description USB3P0_RXDN1 Table 3-35: USB 3.0 Port Pinouts 3.3.6 VGA Connector CN Label: VGA1 15-pin Female CN Type: CN Location: See Figure 3-31 CN Pinouts: See Table 3-36 and Figure 3-35 Both VGA connectors can be connected to monitors that accept standard VGA input for easy dual display setup.

  • Page 67: Installation

    NANO-BT-i1 EPIC SBC Chapter Installation Page 53...

  • Page 68: Anti-Static Precautions

    NANO-BT-i1 EPIC SBC 4.1 Anti-static Precautions WARNING: Failure to take ESD precautions during the installation of the NANO-BT-i1 may result in permanent damage to the NANO-BT-i1 and severe injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the NANO-BT-i1.
  • Page 69 NANO-BT-i1 EPIC SBC WARNING: The installation instructions described in this manual should be carefully followed in order to prevent damage to the components and injury to the user. Before and during the installation please DO the following:  Read the user manual: The user manual provides a complete description of the NANO-BT-i1 installation instructions and configuration options.

  • Page 70: So-Dimm Installation

    NANO-BT-i1 EPIC SBC 4.2.1 SO-DIMM Installation To install an SO-DIMM, please follow the steps below and refer to Figure 4-1. Figure 4-1: SO-DIMM Installation Step 1: Locate the SO-DIMM socket on the solder side of the NANO-BT-i1. Place the board on an anti-static mat. Step 2: Align the SO-DIMM with the socket.

  • Page 71: Figure 4-2: Iris-1010 Module Installation

    NANO-BT-i1 EPIC SBC Figure 4-2: iRIS-1010 Module Installation Step 1: Locate the iRIS module slot on the solder side. See Figure 3-14. Step 2: Insert into the socket at an angle. Line up the notch on the RIS-1010 module with the notch on the connector. Slide the RIS-1010 module into the socket at an angle of about 20º.

  • Page 72: Pcie Mini Card Installation

    NANO-BT-i1 EPIC SBC 4.2.3 PCIe Mini Card Installation To install the PCIe Mini card, please refer to the diagram and instructions below. Figure 4-3: PCIe Mini Card Installation Step 1: Insert into the socket at an angle. Line up the notch on the card with the notch on the connector.

  • Page 73: Clear Cmos Button

    NANO-BT-i1 EPIC SBC Figure 4-4: AT/ATX Power Mode Switch Location 4.3.2 Clear CMOS Button To reset the BIOS, remove the on-board battery and press the clear CMOS button for three seconds or more. The clear CMOS button location is shown in Figure 4-5. Figure 4-5: Clear CMOS Button Location Page 59...

  • Page 74: Lvds Panel Resolution Selection

    NANO-BT-i1 EPIC SBC 4.3.3 LVDS Panel Resolution Selection Use the SW1 DIP switch to select the resolution of the LCD panel connected to the LVDS connector. SW1 (4-3-2-1) Description 0000 800x600 18-bit (Default) 0001 1024x768 18-bit 0010 1024x768 24-bit 0011 1280x768 18-bit 0100 1280x800 18-bit...

  • Page 75: Lcd Voltage Selection

    NANO-BT-i1 EPIC SBC Figure 4-6: LVDS Panel Resolution Selection Switch Location 4.3.4 LCD Voltage Selection The LCD voltage selection switch sets the voltage of the power supplied to the LCD panel. The LCD Voltage Selection settings are shown in Table 4-2. Setting Description +3.3 V (Default)

  • Page 76: Msata/Sata Selection

    NANO-BT-i1 EPIC SBC Figure 4-7: LCD Voltage Selection Switch Location 4.3.5 mSATA/SATA Selection Use the J_SATA1 switch to select whether to automatically detect mSATA devices. Setting Description Automatically detect mSATA device (Default) Enable mSATA device Table 4-3: mSATA/SATA Switch Settings Figure 4-8: mSATA/SATA Switch Location Page 62...

  • Page 77: Voltage Selection

    NANO-BT-i1 EPIC SBC 4.3.6 PCI-104 Voltage Selection Use the J_PCI104 switch to select the voltage supplied to the PCI-104 expansion module. Setting Description +3.3 V (Default) +5.0 V Table 4-4: PCI-104 Voltage Switch Settings Figure 4-9: PCI-104 Voltage Switch Location 4.4 Internal Peripheral Device Connections This section outlines the installation of peripheral devices to the on-board connectors.

  • Page 78: Figure 4-10: Power Cable To Motherboard Connection

    NANO-BT-i1 EPIC SBC Step 2: Connect the Power Cable to the Motherboard. Connect the 4-pin (2x2) Molex type power cable connector to the +12V power connector on the motherboard. See Figure 4-10. Figure 4-10: Power Cable to Motherboard Connection Step 3: Connect Power Cable to Power Supply.

  • Page 79: Sata Drive Connection

    NANO-BT-i1 EPIC SBC Figure 4-11: Connect Power Cable to Power Supply 4.4.2 SATA Drive Connection The NANO-BT-i1 is shipped with two SATA drive cables. To connect the SATA drive to the connector, please follow the steps below. Step 1: Locate the SATA connector and the SATA power connector. The locations of the connectors are shown in Chapter 3.

  • Page 80: Single Rs-232 Cable Connection

    NANO-BT-i1 EPIC SBC Figure 4-12: SATA Drive Cable Connection Step 3: Connect the cable to the SATA disk. Connect the connector on the other end of the cable to the connector at the back of the SATA drive. See Figure 4-12. Step 4: To remove the SATA cable from the SATA connector, press the clip on the connector at the end of the cable.

  • Page 81: External Peripheral Interface Connection

    NANO-BT-i1 EPIC SBC Figure 4-13: Single RS-232 Cable Installation Step 3: Secure the bracket. The single RS-232 connector has one D-sub 9 male connector secured to a bracket. To secure the bracket to the chassis please refer to the reference material that came with the chassis. Step 0: 4.5 External Peripheral Interface Connection This section describes connecting devices to the external connectors on the NANO-BT-i1.

  • Page 82: Ps/2 Keyboard/Mouse Connection

    NANO-BT-i1 EPIC SBC Figure 4-14: LAN Connection Step 3: Insert the LAN cable RJ-45 connector. Once aligned, gently insert the LAN cable RJ-45 connector into the on-board RJ-45 connector. 4.5.2 PS/2 Keyboard/Mouse Connection The NANO-BT-i1 has a single PS/2 connector on the external peripheral interface panel. The PS/2 connector is connected to the optional PS/2 Y-cable which can be purchased separately.

  • Page 83: Usb Connection

    NANO-BT-i1 EPIC SBC Figure 4-15: PS/2 Keyboard/Mouse Connector Step 3: Connect the keyboard and mouse. Connect the keyboard and mouse to the appropriate connector. The keyboard and mouse connectors can be distinguished from each other by looking at the small graphic at the top of the connector.

  • Page 84: Vga Monitor Connection

    NANO-BT-i1 EPIC SBC Step 2: Insert a USB Series "A" plug. Insert the USB Series "A" plug of a device into the USB Series "A" receptacle on the external peripheral interface. See Figure 4-16. Figure 4-16: USB Connector 4.5.4 VGA Monitor Connection The NANO-BT-i1 has one single female D-sub 15 connector on the external peripheral interface panel.

  • Page 85: Figure 4-17: Vga Connector

    NANO-BT-i1 EPIC SBC Step 3: Insert the VGA connector. Once the connectors are properly aligned, insert the male connector from the VGA screen into the female connector on the NANO-BT-i1. See Figure 4-17. Figure 4-17: VGA Connector Step 4: Secure the connector. Secure the D-sub 15 VGA connector from the VGA monitor to the external interface by tightening the two retention screws on either side of the connector.

  • Page 86: Ipmi Setup Procedure

    NANO-BT-i1 EPIC SBC 4.6 IPMI Setup Procedure The NANO-BT-i1 features Intelligent Platform Management Interface (IPMI) that helps lower the overall costs of server management by enabling users to maximize IT resources, save time and manage multiple systems. The NANO-BT-i1 supports IPMI 2.0 through the optional iRIS-1010 module.

  • Page 87: Bios

    NANO-BT-i1 EPIC SBC Chapter BIOS Page 73...

  • Page 88: Introduction

    NANO-BT-i1 EPIC SBC 5.1 Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. NOTE: Some of the BIOS options may vary throughout the life cycle of the product and are subject to change without prior notice.

  • Page 89: Getting Help

    NANO-BT-i1 EPIC SBC Function Decrease the numeric value or make changes Esc key Main Menu – Quit and not save changes into CMOS Status Page Setup Menu and Option Page Setup Menu -- Exit current page and return to Main Menu F1 key General help, only for Status Page Setup Menu and Option Page Setup Menu...

  • Page 90: Main

    NANO-BT-i1 EPIC SBC The following sections completely describe the configuration options found in the menu items at the top of the BIOS screen and listed above. 5.2 Main The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information.

  • Page 91: Advanced

    NANO-BT-i1 EPIC SBC  System Time [xx:xx:xx] Use the System Time option to set the system time. Manually enter the hours, minutes and seconds. 5.3 Advanced Use the Advanced menu (BIOS Menu 2) to configure the CPU and peripheral devices through the following sub-menus: WARNING! Setting the wrong values in the sections below may cause the system...

  • Page 92: Bios Menu 3: Acpi Configuration

    NANO-BT-i1 EPIC SBC Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc. Advanced ACPI Settings Select the highest ACPI sleep state the system ACPI Sleep State [S3 (Suspend to RAM)] will enter when the SUSPEND button is pressed. ---------------------- : Select Screen ...

  • Page 93: Super Io Configuration

    NANO-BT-i1 EPIC SBC 5.3.2 Super IO Configuration Use the Super IO Configuration menu (BIOS Menu 4) to set or change the configurations for the serial ports. Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc. Advanced F81866 Super IO Configuration Set Parameters of Serial Port 1 (COMA) F81866 Super IO Chip...
  • Page 94 NANO-BT-i1 EPIC SBC 5.3.2.1.1 Serial Port 1 Configuration  Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port.  Disabled Disable the serial port  Enable the serial port Enabled EFAULT  Change Settings [Auto] Use the Change Settings option to change the serial port IO port address and interrupt address.
  • Page 95 NANO-BT-i1 EPIC SBC 5.3.2.1.2 Serial Port 2 Configuration  Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port.  Disabled Disable the serial port  Enable the serial port Enabled EFAULT  Change Settings [Auto] Use the Change Settings option to change the serial port IO port address and interrupt address.
  • Page 96 NANO-BT-i1 EPIC SBC  IO=2E8h; Serial Port I/O port address is 2E8h and the interrupt IRQ=3, address is IRQ3, 4, 5, 6, 7, 9, 10, 11, 12 5, 6, 7, 9, 10, 11, 12 5.3.2.1.3 Serial Port 3 Configuration  Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port.
  • Page 97 NANO-BT-i1 EPIC SBC  IO=3E8h; Serial Port I/O port address is 3E8h and the interrupt IRQ=3, address is IRQ3, 4, 5, 6, 7, 9, 10, 11, 12 5, 6, 7, 9, 10, 11, 12  Serial Port I/O port address is 2E8h and the interrupt IO=2E8h;...

  • Page 98: Hardware Monitor

    NANO-BT-i1 EPIC SBC  IO=2E8h; Serial Port I/O port address is 2E8h and the interrupt IRQ=7 address is IRQ7  Serial Port I/O port address is 3F8h and the interrupt IO=3F8h; address is IRQ3, 4, 5, 6, 7, 9, 10, 11, 12 IRQ=3, 5, 6, 7, 9, 10, 11, 12...

  • Page 99: Bios Menu 6: Hardware Monitor

    NANO-BT-i1 EPIC SBC Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc. Advanced PC Health Status Enable or Disable Smart Smart Fan Function [Enabled] > Smart Fan Mode Configuration SYS Temperature :+42 C CPU_FAN1 :N/A SYS_FAN1 :N/A --------------------- : Select Screen VIN1 :+0.864 V ...

  • Page 100: Smart Fan Mode Configuration

    NANO-BT-i1 EPIC SBC VIN3 VIN4 VCC3V VSB3V VSB5V 5.3.3.1 Smart Fan Mode Configuration Use the Smart Fan Mode Configuration submenu (BIOS Menu 7) to configure smart fan temperature and speed settings. Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc. Advanced Smart Fan Mode Configuration Smart Fan Mode Select...

  • Page 101: Iwdd H/W Monitor

    NANO-BT-i1 EPIC SBC  CPU/System Temperature 1 Use the + or – key to change the CPU/System Temperature 1 value. Enter a decimal number between 1 and 100. If CPU/System temperature is higher than this setting, the fan duty cycle is 100. ...

  • Page 102: Bios Menu 8: Iwdd H/W Monitor

    NANO-BT-i1 EPIC SBC Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc. Advanced PC Health Status Smart Fan Mode Select SYS Temperature :+42 C CPU_FAN1 Speed :N/A SYS_FAN1 Speed :N/A --------------------- : Select Screen CPU_CORE :+1.864 V  : Select Item :+5.106 V +12V :+12.175 V...

  • Page 103: Smart Fan Mode Configuration

    NANO-BT-i1 EPIC SBC 5.3.4.1 Smart Fan Mode Configuration Use the Smart Fan Mode Configuration submenu (BIOS Menu 9) to configure smart fan temperature and speed settings. Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc. Advanced Smart Fan Mode Configuration Smart Fan Mode Select CPU_FAN1 Smart Fan Control [Auto Mode]...

  • Page 104: Rtc Wake Settings

    NANO-BT-i1 EPIC SBC  Auto mode fan start PWM Use the + or – key to change the Auto mode fan start PWM value. Enter a decimal number between 1 and 100.  Auto mode fan slope PWM Use the + or – key to change the Auto mode fan slope PWM value. Enter a decimal number between 1 and 64.

  • Page 105: Serial Port Console Redirection

    NANO-BT-i1 EPIC SBC  Disabled The real time clock (RTC) cannot generate a wake EFAULT event  If selected, the following appears with values that Enabled can be selected: *Wake up every day *Wake up date *Wake up hour *Wake up minute *Wake up second After setting the alarm, the computer turns itself on from a suspend state when the alarm goes off.
  • Page 106 NANO-BT-i1 EPIC SBC  Console Redirection [Disabled] Use Console Redirection option to enable or disable the console redirection function.  Disabled the console redirection function Disabled EFAULT  Enabled Enabled the console redirection function The following options are available in the Console Redirection Settings submenu when the Console Redirection option is enabled.

  • Page 107: Cpu Configuration

    NANO-BT-i1 EPIC SBC  Sets the data bits at 8. EFAULT  Parity [None] Use the Parity option to specify the parity bit that can be sent with the data bits for detecting the transmission errors.  No parity bit is sent with the data bits. None EFAULT ...

  • Page 108: Bios Menu 12: Cpu Configuration

    NANO-BT-i1 EPIC SBC Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc. Advanced CPU Configuration Number of cores to enable in each processor CPU Signature 30673 package. Microcode Patch Max CPU Speed 1910 MHz Min CPU Speed 500 MHz Processor Cores Intel HT Technology Not Supported...
  • Page 109 NANO-BT-i1 EPIC SBC  Active Processor Cores [All] Use the Active Processor Cores BIOS option to enable numbers of cores in the processor package.  Enable all cores in the processor package. EFAULT  Enable one core in the processor package. ...

  • Page 110: Ide Configuration

    NANO-BT-i1 EPIC SBC 5.3.8 IDE Configuration Use the IDE Configuration menu (BIOS Menu 13) to change and/or set the configuration of the SATA devices installed in the system. Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc. Advanced Serial-ATA (SATA) [Enabled] Enable/Disable Serial SATA Mode...

  • Page 111: Usb Configuration

    NANO-BT-i1 EPIC SBC 5.3.9 USB Configuration Use the USB Configuration menu (BIOS Menu 14) to read USB configuration information and configure the USB settings. Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc. Advanced USB Configuration Enables Legacy USB support.

  • Page 112: Chipset

    NANO-BT-i1 EPIC SBC  Disabled Legacy USB support disabled  Legacy USB support disabled if no USB devices are Auto connected 5.4 Chipset Use the Chipset menu (BIOS Menu 15) to access the North Bridge and South Bridge subsystem configuration menus. WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction.

  • Page 113: North Bridge

    NANO-BT-i1 EPIC SBC 5.4.1 North Bridge Use the North Bridge menu (BIOS Menu 16) to configure the north bridge parameters. Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc. Chipset > Intel IGD Configuration Configure Intel IGD Settings. Memory Information Total Memory 4096 MB (LPDDR3) ---------------------...

  • Page 114: Intel Igd Configuration

    NANO-BT-i1 EPIC SBC 5.4.1.1 Intel IGD Configuration Use the Intel IGD Configuration submenu (BIOS Menu 17) to configure the graphics settings. Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc. Chipset Intel IGD Configuration Select which of IGD/PCI Graphics device should Primary Display [IGD] be Primary Display.

  • Page 115: South Bridge

    NANO-BT-i1 EPIC SBC  128M 128 MB of memory used by internal graphics device  256 MB of memory used by internal graphics 256M device  512M 512 MB of memory used by internal graphics device  DVMT Total Gfx Mem [256MB] Use the DVMT Total Gfx Mem option to specify the maximum amount of memory that can be allocated as graphics memory.
  • Page 116 NANO-BT-i1 EPIC SBC  Restore on AC Power Loss [Last State] Use the Restore on AC Power Loss BIOS option to specify what state the system returns to if there is a sudden loss of power to the system.  Power Off The system remains turned off ...

  • Page 117: Pci Express Configuration

    NANO-BT-i1 EPIC SBC 5.4.2.1 PCI Express Configuration Use the PCI Express Configuration submenu (BIOS Menu 19) to configure the PCI Express slots. Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc. Chipset PCI Express Configuration Enable or Disable the PCI PCI-E Mini Card (CN8) [Enabled] Express Port 2 in the...

  • Page 118: Security

    NANO-BT-i1 EPIC SBC 5.5 Security Use the Security menu (BIOS Menu 20) to set system and user passwords. Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc. Main Advanced Chipset Security Boot Save & Exit Password Description Set Administrator Password If ONLY the Administrator’s password is set, then this only limits access to Setup and is...

  • Page 119: Boot

    NANO-BT-i1 EPIC SBC 5.6 Boot Use the Boot menu (BIOS Menu 21) to configure system boot options. Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc. Main Advanced Chipset Security Boot Save & Exit Boot Configuration Select the keyboard Bootup NumLock State [On] NumLock state...
  • Page 120 NANO-BT-i1 EPIC SBC  Quiet Boot [Enabled] Use the Quiet Boot BIOS option to select the screen display when the system boots.  Normal POST messages displayed Disabled  Enabled OEM Logo displayed instead of POST messages EFAULT  UEFI Boot [Disabled] Use the UEFI Boot option to enable or disable to boot from a UEFI device.

  • Page 121: Exit

    NANO-BT-i1 EPIC SBC  Legacy Launch legacy video OpROM. EFAULT only  Option ROM Messages [Force BIOS] Use the Option ROM Messages option to set the Option ROM display mode.  Sets display mode to force BIOS. Force EFAULT BIOS ...
  • Page 122 NANO-BT-i1 EPIC SBC  Save Changes and Reset Use the Save Changes and Reset option to save the changes made to the BIOS options and reset the system.  Discard Changes and Reset Use the Discard Changes and Reset option to exit the system without saving the changes made to the BIOS configuration setup program.

  • Page 123: Software Drivers

    NANO-BT-i1 EPIC SBC Chapter Software Drivers Page 109...

  • Page 124: Available Software Drivers

    NANO-BT-i1 EPIC SBC 6.1 Available Software Drivers NOTE: The content of the CD may vary throughout the life cycle of the product and is subject to change without prior notice. Visit the IEI website or contact technical support for the latest updates. The following drivers can be installed on the system: ...

  • Page 125: Figure 6-1: Driver Cd Main Menu

    NANO-BT-i1 EPIC SBC Figure 6-1: Driver CD Main Menu Step 4: A new screen with a list of available drivers appears (Figure 6-2). Figure 6-2: Available Drivers Page 111...

  • Page 126: Chipset Driver Installation

    NANO-BT-i1 EPIC SBC Step 5: Install all of the necessary drivers in the menu. 6.3 Chipset Driver Installation To install the chipset driver, please do the following. Step 1: Access the driver list. (See Section 6.2) Step 2: Click “1-Bay Trail SOC” and select the folder which corresponds to the operating system.

  • Page 127: Figure 6-4: Chipset Driver License Agreement

    NANO-BT-i1 EPIC SBC Step 5: The License Agreement in Figure 6-4 appears. Step 6: Click Yes to accept the agreement and continue. Figure 6-4: Chipset Driver License Agreement Step 7: The Read Me file in Figure 6-5 appears. Step 8: Click Next to continue.

  • Page 128: Figure 6-6: Chipset Driver Setup Operations

    NANO-BT-i1 EPIC SBC Step 9: Setup Operations are performed as shown in Figure 6-6. Step 10: Once the Setup Operations are complete, click Next to continue. Figure 6-6: Chipset Driver Setup Operations Step 11: The Finish screen in Figure 6-7 appears. Step 12: Select “Yes, I want to restart this computer now”...

  • Page 129: Graphics Driver Installation

    NANO-BT-i1 EPIC SBC 6.4 Graphics Driver Installation To install the Graphics driver, please do the following. Step 1: Access the driver list. (See Section 6.2) Step 2: Click “1-Bay Trail SOC” and select the folder which corresponds to the operating system. NOTE: The remainder of this installation assumes Windows 8 as the operating system.

  • Page 130: Figure 6-8: Graphics Driver Welcome Screen

    NANO-BT-i1 EPIC SBC Figure 6-8: Graphics Driver Welcome Screen Step 6: The License Agreement in Figure 6-9 appears. Step 7: Click Yes to accept the agreement and continue. Figure 6-9: Graphics Driver License Agreement Step 8: The Read Me file in Figure 6-10 appears. Click Next to continue. Page 116...

  • Page 131: Figure 6-10: Graphics Driver Read Me File

    NANO-BT-i1 EPIC SBC Figure 6-10: Graphics Driver Read Me File Step 9: Setup Operations are performed as shown in Figure 6-11. Step 10: Once the Setup Operations are complete, click Next to continue. Figure 6-11: Graphics Driver Setup Operations Step 11: The system starts installing the Graphics Driver.

  • Page 132: Lan Driver Installation

    NANO-BT-i1 EPIC SBC Step 13: Select “Yes, I want to restart this computer now” and click Finish. Step 0: Figure 6-12: Graphics Driver Installation Finish Screen 6.5 LAN Driver Installation To install the LAN driver, please do the following. Step 1: Right-click This PC icon on the desktop and select Properties.

  • Page 133: Figure 6-13: Pc Properties

    NANO-BT-i1 EPIC SBC Figure 6-13: PC Properties Step 2: The system control panel window in Figure 6-14 appears. Step 3: Click the Device Manager link (Figure 6-14). Figure 6-14: System Control Panel Page 119...

  • Page 134: Figure 6-15: Device Manager List

    NANO-BT-i1 EPIC SBC Step 4: A list of system hardware devices appears (Figure 6-15). Step 5: Right-click one of the Ethernet controllers that has question marks next to it (this means Windows does not recognize the device). Step 6: Select Update Driver Software. See Figure 6-15. Figure 6-15: Device Manager List Step 7: The Update Driver Software Window appears (Figure 6-16).

  • Page 135: Figure 6-16: Update Driver Software Window

    NANO-BT-i1 EPIC SBC Figure 6-16: Update Driver Software Window Step 8: Select “Browse my computer for driver software” and click N to continue. Step 9: Click Browse to select “X:\2-LAN\Intel” directory in the Locate File window, where “X:\” is the system CD drive. (Figure 6-17). Figure 6-17: Locate Driver Files Step 10: Click N...
  • Page 136 NANO-BT-i1 EPIC SBC Step 11: Driver Installation is performed. When the Finish screen appears, click Close to exit. Step 12: Right-click the other Ethernet controller that has question marks next to it as shown in Figure 6-15. Repeat Step 6–Step 11 to install the second Ethernet controller driver.

  • Page 137: Abios Options

    NANO-BT-i1 EPIC SBC Appendix BIOS Options Page 123...
  • Page 138 NANO-BT-i1 EPIC SBC Below is a list of BIOS configuration options in the BIOS chapter. 　 System Date [xx/xx/xx] ......................76 　 System Time [xx:xx:xx] .......................77 　 ACPI Sleep State [S3 (Suspend to RAM)]................78 　 Serial Port [Enabled]......................80 　 Change Settings [Auto] .......................80 　...
  • Page 139 NANO-BT-i1 EPIC SBC 　 EIST [Enabled]........................95 　 Serial-ATA (SATA) [Enabled] ....................96 　 SATA Mode Selection [IDE Mode] ..................96 　 USB Devices .........................97 　 Legacy USB Support [Enabled]..................97 　 Primary Display [IGD] ....................... 100 　 DVMT Pre-Allocated [64M] ....................100 　 DVMT Total Gfx Mem [256MB] ..................

  • Page 140: B Terminology

    NANO-BT-i1 EPIC SBC Appendix Terminology Page 126...
  • Page 141 NANO-BT-i1 EPIC SBC AC ’97 Audio Codec 97 (AC’97) refers to a codec standard developed by Intel® in 1997. ACPI Advanced Configuration and Power Interface (ACPI) is an OS-directed configuration, power management, and thermal management interface. AHCI Advanced Host Controller Interface (AHCI) is a SATA Host controller register-level interface.
  • Page 142 NANO-BT-i1 EPIC SBC DIMM Dual Inline Memory Modules are a type of RAM that offer a 64-bit data bus and have separate electrical contacts on each side of the module. The digital inputs and digital outputs are general control signals that control the on/off circuit of external devices or TTL devices.
  • Page 143 NANO-BT-i1 EPIC SBC LVDS Low-voltage differential signaling (LVDS) is a dual-wire, high-speed differential electrical signaling system commonly used to connect LCD displays to a computer. POST The Power-on Self Test (POST) is the pre-boot actions the system performs when the system is turned-on. Random Access Memory (RAM) is volatile memory that loses data when power is lost.

  • Page 144: C Watchdog Timer

    NANO-BT-i1 EPIC SBC Appendix Watchdog Timer Page 130...
  • Page 145 NANO-BT-i1 EPIC SBC NOTE: The following discussion applies to DOS environment. Contact IEI support or visit the IEI website for specific drivers for other operating systems. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash. This condition may have occurred by external EMIs or a software bug.
  • Page 146 NANO-BT-i1 EPIC SBC NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. EXAMPLE PROGRAM: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30 ;time-out value is 48 seconds ;...

  • Page 147: D Digital I/O Interface

    NANO-BT-i1 EPIC SBC Appendix Digital I/O Interface Page 133...

  • Page 148: Introduction

    NANO-BT-i1 EPIC SBC D.1 Introduction The DIO connector on the NANO-BT-i1 is interfaced to GPIO ports on the Super I/O chipset. The DIO has both 4-bit digital inputs and 4-bit digital outputs. The digital inputs and digital outputs are generally control signals that control the on/off circuit of external devices or TTL devices.

  • Page 149: Assembly Language Sample

    NANO-BT-i1 EPIC SBC D.2 Assembly Language Sample 1 AX, 6F08H ;setting the digital port as input AL low byte = value AH – 6FH Sub-function: AL – 9 :Set the digital port as OUTPUT :Digital I/O input value D.3 Assembly Language Sample 2 AX, 6F09H ;setting the digital port as output BL, 09H...

  • Page 150: E Hazardous Materials Disclosure

    NANO-BT-i1 EPIC SBC Appendix Hazardous Materials Disclosure Page 136...

  • Page 151: Hazardous Materials Disclosure Table For Ipb Products Certified As Rohs Compliant Under 2002/95/Ec Without Mercury

    NANO-BT-i1 EPIC SBC E.1 Hazardous Materials Disclosure Table for IPB Products Certified as RoHS Compliant Under 2002/95/EC Without Mercury The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 152 NANO-BT-i1 EPIC SBC Part Name Toxic or Hazardous Substances and Elements Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated (Pb) (Hg) (Cd) Chromium Biphenyls Diphenyl (CR(VI)) (PBB) Ethers (PBDE) Housing Display Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Power Supply Assemblies Battery This toxic or hazardous substance is contained in all of the homogeneous materials for the part is...
  • Page 153 NANO-BT-i1 EPIC SBC 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯 醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11363-2006 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11363-2006 标准规定的限量要求。 Page 139...

Table of Contents
