Configuring the IO-Link Master with GSD file
1. Install the GSD file in
2. Select the IO-Link Master I/O device in the hardware catalog of
3. You can freely choose the address space in the Properties > Addresses field for each slot
4. Assign the IO-Link Master parameters. You can assign the parameters separately for a
Configuring the IO-Link Devices using
1. Select the Slot 1 "4 IO-L" from the configuration table of the I/O device IO-Link Master.
2. Right-click and select "Start Device Tool" in the following shortcut menu.
3. Now start with the parameter assignment of the IO-Link Devices, sensors, and actuators.
Additional information is available in the
Behavior in non-parameterized status and after "Reset to factory settings"
● All ports of the IO-Link Master are deactivated.
● All user data are equal to 0.
● All bits of the value status are set to "invalid."
● The maintenance data 1 to 3 are deleted.
ET 200eco PN
Operating Instructions, 06/2009, A5E01250250-04
HW Config
of the IO-Link Master. In contrast to HSP configuration, the address space on Slot 1
"4 IO-L" is set permanently to 32-byte inputs and outputs. Additional information on
possible configurations is available in the chapter I/O address space (Page 195).
functional unit:
– The PROFINET IO parameters are accessed by double-clicking Slot 0.
– The IO-Link parameters are accessed by double-clicking Slot 1.
– The 8 digital input and 4 digital output parameters are accessed by double-clicking
Slot 2.
S7-PCT
S7-PCT
Result:
is started.
. The GSD file is available on the Internet.
S7-PCT
online help.
4.2 Configuring the IO-Link Master
HW Config
.
Configuring
63
