Technical data
Sensor selection data
Input ranges (nominal value)/input resistance
or input voltage




Permissible input voltage for voltage input
(destruction limit)
Connection of sensors for voltage
measurement
Connection of sensors for current
measurement
Connection of sensors for RTD
Connection of sensors for thermocouples
Temperature compensation


Technical unit for temperature measurement
Formation of analog values
Measuring principle
Integration time and conversion time/resolution
(per channel)





ET 200eco PN
Operating Instructions, 06/2009, A5E01250250-04
Voltage
Current
Resistor and thermal resistor
Thermocouple
Internal temperature compensation
External temperature compensation
Integration time parameterizable
Interference frequency suppression in Hz
Integration time in ms
Conversion time in ms (per channel) *
Resolution for voltage (including
overrange)
I/O device analog input/output
11.1 I/O device analog input
±80 mV/10 MΩ
±10 V/100 kΩ
0 to 10 V/100 kΩ
1 to 5 V/100 kΩ
±20 mA/17 V for 2 DMU, 3.5 V for 4 DMU
0 to 20 mA/17 V for 2 DMU, 3.5 V for 4 DMU
4 to 20 mA/17 V for 2 DMU, 3.5 V for 4 DMU
150 Ω/10 MΩ
300 Ω/10 MΩ
600 Ω/10 MΩ
3000 Ω/10 MΩ
Ni100/10 MΩ
Ni1000/10 MΩ
Ni120/10 MΩ
Ni200/10 MΩ
Ni500/10 MΩ
Pt100/10 MΩ
Pt1000/10 MΩ
Pt200/10 MΩ
Pt500/10 MΩ
Types E, J, K, N
28.8 V continuous, 35 V for max. duration of 500 ms
Yes
Yes (as 2-wire/4-wire transducer)
Yes (with 2-/3-/4-conductor connection)
Yes
Yes, parameterizable
Yes, parameterizable
°C/°F/K
Integrating
Yes
500/60/50/10
2,0/16,667/20/100
4/19/22/102
±80 mV/15 bits + sign
±10 V/15 bits + sign
0 to 10 V/15 bits
1 to 5 V/15 bits
