Technical data
Number of inputs that can be controlled
simultaneously
Insulation
Insulation test voltage
Ethernet interface
Electrical isolation




Permissible potential difference
Status, interrupts, diagnostics
Interrupts
Diagnostics function









Monitoring for





Sensor supply
Number of sensor supplies
Load current
Short-circuit protection
Sensor selection data
Cable length, shielded
ET 200eco PN
Operating Instructions, 06/2009, A5E01250250-04
Between 1L+ and 2L+
Between 1L+, channels, and all other circuit
elements
Between channels
Between Ethernet and all other circuit
elements
Group error/maintenance
Bus monitoring PROFINET IO
Monitoring of supply voltage 1L+
Existing connection to network
Digital input
Fault at digital input
Digital output
Fault at digital output
Diagnostic information can be read
Failure of 1L+ and 2L+
Short circuit of the sensor supply
Digital output short-circuit
Digital input wire break
Digital output wire break
I/O device digital inputs/outputs
9.3 I/O device digital inputs/outputs
8, at all mounting positions
500 V DC
1500 Vrms (IEEE802.3)
Yes
No
No
Yes
75 V DC, 60 V AC
Yes
Yes
Red/yellow "SF/MT" LED
Red "BF" LED
Green "ON" LED
Green "P1 LK" and "P2 LK" LED; LED for
PROFINET IO infeed and loop-through
Green LED
Red LED
Green LED
Red LED
Yes
Yes
Yes, per channel
Yes, per channel
Yes, input current < 0.3 mA, per channel
Yes, in the off state, per channel
8, 4×1L+ and 4×2L+
Note: The sensor supply is only available when
the corresponding channel is parameterized as
an "Input".
100 mA per output
Yes, electronic
Max. 30 m
