2.4 Extending Module Connection

®
2N Helios IP Base
RFID card reader 125 kHz
RFID card reader 13.56 MHz
Security Relay

Module Bus Interconnection

®
All modules 2N Helios IP Base
connector is shown in Fig. Before connecting RFID card reader it is suitable to
®
disconnect 2N Helios IP Base
connected at a time.

How to install modules:

1) On the picture there is a highlighted connector X12. This connector is designed to
connect the module to the main unit.
2N TELEKOMUNIKACE a.s., www.2n.cz
allows to connect following extending modules:
, are connected via connector X12, the position of this
from the power supply. Only one module can be
33/60
