EM4100, EM4102, HID Proximity

RFID Card Reader 13.56 MHz

The 13.56 MHz RFID Card Reader ( Part No. 9156031) is one of the 2N
intercom elements and is used for reading RFID card Ids in the 13.56 MHz band.
The following RFID cards can be read (only card serial number is read):
ISO/IEC 14443A Mifare Classic 1k & 4k, DESFire EV1, Mini, Plus S&X, Ultralight,
Ultralight C
ISO/IEC 14443B CEPAS, HID iCLASS – CSN only
JIS X 6319 Felica

Security Relay

®
The 2N Helios IP
between the intercom and the connected electric lock. The 2N
Relay is designed for any
higher. It significantly enhances security of the connected electric lock as it prevents
lock opening by forced intercom tampering.
Function:
®
The 2N Helios IP Security Relay
the secured area) and the electric lock (inside the secured area). The 2N
Security Relay includes a relay that can only be activated if the valid opening code is
received from the intercom.

Specifications:

Passive switch: NO and NC contacts, up to 30 V / 1 A AC/DC
Active switch output: 12 V / 700 mA DC
Dimensions: (56 x 31 x 24) mm
Weight: 20 g
2N TELEKOMUNIKACE a.s., www.2n.cz
Security Relay (Part No. 9159010) is used for enhancing security
2N Helios IP
is a device installed between an intercom (outside
intercom model with firmware versions 1.15 and
®
Helios IP Base
®
Helios IP Security
®
Helios IP
