Status Signalling - 2N Helios IP Base Installation Manual

Connection:
®
Connect the 2N Helios IP Security Relay
To the intercom active output (OUT1 or OUT2) , or
To the intercom relay output with a 12 V DC serial external power supply.
Connect the electric lock to the
To the active 12 V / 700 mA DC output, or
To the relay output with a serial external power supply.
The device also supports a Departure button connected between the 'PB' and '-
HeliosIP' terminals. Press the Departure button to activate the output for 5 seconds.

Status signalling:

Green LED Red LED
blinking off
on off
blinking blinking
on blinking
2N TELEKOMUNIKACE a.s., www.2n.cz
to the intercom as follows:
®
2N Helios IP Security Relay
Status
Operational mode
Activated output
Programming mode – waiting for initialisation
Error – wrong code received
output as follows:
38/60
