Chapter 5 – Troubleshooting

Diagnostic Testing

If you suspect that you are having hardware problems with your 4117T, you can use
the Pro-face diagnostic utility to check out the PC's various ports and subsystems.
The diagnostic utility is on the Documentation and Support Library CD that was
included with the your unit.
The first step is to create a diagnostic diskette. The following steps can be done on
any computer with a CD-ROM drive:
1. Create a DOS-bootable diskette
2. Create a temporary folder on the computer hard drive
3. There is a self-extracting zip file on the Documentation and Support Library CD
located in:
Run that program and extract the files to the temporary folder you just created.
4. Copy the extracted files onto the DOS-bootable diskette.
When you have created the diskette, insert it into an external floppy drive, connect it
to the 4117T and re-boot the unit. The menu in Figure 5–2, Main Menu, will appear
following boot-up. Additional information on the tests is included in the .txt files on
the diskette.
Perform the following steps before starting the system tests:
1. Place the CPU board jumpers and switches to the factory set positions.
2. Plug the female end of the AC power cable into the side of the unit and the male
end into a properly grounded outlet.
3. Connect the serial loopback connector(s) and the printer cable to the appropriate
connectors, and connect a PC/AT or PS/2 keyboard. Figure 5–1, Serial Loopback
Connections, illustrates the wiring necessary for the loopback connection.
4. Default the CMOS setup to the factory settings.
DRIVERS\utility\xydiag
63 144811(B)
