4117T Light Duty Industrial PC
Back Panel
The diagram below shows the back panel of the 4117T. For maintenance, installation
or upgrade, first remove the back cover by unfastening 13 screws as shown in the
diagram below.
Before any installation or un-installation, please take precautions to prevent
damage to the components due to static electricity.
Figure 1-2. System Back Panel
Caution
3
Chapter 1 – Introduction
144811(B)
