4117T Light Duty Industrial PC
PW1: ATX Power Connector
DIO1: 8 Bits GPIO Connector
CPU_FAN1,SYS_FAN1,SYS_FAN2: Fan Connector
PIN NO. DESCRIPTION
1 3.3V
2 3.3V
3 GND
4 5V
5 GND
6 5V
7 GND
8 PWR OK
9 5VSB
10 12V
PIN NO. DESCRIPTION
1 GND
3 GPIO0
5 GPIO2
7 GPIO4
9 GPIO6
PIN NO.
1
2
3
27
Chapter 3 – ICPMB-7570 CPU Board & BIOS Setup
PIN NO. DESCRIPTION
11 3.3V
12 -12V
13 GND
14 PSON
15 GND
16 GND
17 GND
18 -5V
19 5V
20 5V
PIN NO. DESCRIPTION
2 VCC5
4 GPIO1
6 GPIO3
8 GPIO5
10 GPIO7
DESCRIPTION
Fan Speed Detect
+12V
GND
