Xycom 4117T User Manual page 29

4117T Light Duty Industrial PC
USB1: USB(0~1) Connector
USB2: USB(2~3) Connector(2*4 Pin header)
USB3,USB4: USB(4~5) Connector(1*5 Pin header)
LAN1: DUAL RJ45 Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 USBVCC0
3 D0-
5 D0+
7 USBGND0
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 USBVCC2
3 D2-
5 D2+
7 USBGND2
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND
3 GND
5 D4-
PIN NO. Description
A1 MDIOA0+
A2 MDIOA0-
A3 MDIOA1+
A4 MDIOA1-
A5 MDIOA2+
A6 MDIOA2-
A7 MDIOA3+
A8 MDIOA3-
A9 NC
A10 NC
A11 LINK1000
A12 LINK100
A13 ACT
A14 LINK
A15-17 GND
25
Chapter 3 – ICPMB-7570 CPU Board & BIOS Setup
2 USBVCC1
4 D1-
6 D1+
8 USBGND1
2 USBGND3
4 D3+
6 D3-
8 USBVCC3
2 USBVCC4
4 D4+
PIN NO. Description
B1 MDIOB0+
B2 MDIOB0-
B3 MDIOB1+-
B4 MDIOB1-
B5 NC
B6 NC
B7 NC-
B8 NC
B9 NC
B10 NC
B11 VCC
B12 LINK100
B13 ACT
B14 LINK
B15-17 GND
144811(B)
