4117T Light Duty Industrial PC
CN8: LCD LVDS Interface Connector
CN3: Inverter Power Connector
PIN NO. Description
1 GND
3 LVDS_Y3+
5 LVDS_CLK+
7 LVDS_Y2+
9 LVDS_Y1+
11 LVDS_Y0+
13 GND
15 LVDSB_Y3+
17 LVDSBCLK+
19 LVDSB_Y2+
21 LVDSB_Y1+
23 LVDSB_Y0+
25 GND
27 VCC_LCD
29 VCC_LCD
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 VCC12
3 BKLT_EN
5 GND
26
Chapter 3 – ICPMB-7570 CPU Board & BIOS Setup
PIN NO. Description
2 GND
4 LVDS_Y3-
6 LVDS_CLK-
8 LVDS_Y2-
10 LVDS_Y1-
12 LVDS_Y0-
14 GND
16 LVDSB_Y3-
18 LVDSBCLK-
20 LVDSB_Y2-
22 LVDSB_Y1-
24 LVDSB_Y0-
26 GND
28 VCC_LCD
30 VCC_LCD
2 VCC12
4 BKLT_ADJ
6 GND
