4117T Thin Line Industrial Flat Panel PC

Mounting Options

The 4117T can be mounted to a panel, to the wall, or to an arm. The following
sections describe each mounting option for the 4117T.

Panel Mounting

The 4117T is designed for panel mounting. Before mounting the 4117T to the panel,
check the cut out dimensions as shown in Figure 2-2. Then, mount it to the panel
using twelve supporters, as shown in the Figure 2-3 and Figure 2-4 (see next page).
13.1" (332.74mm)
13.59" (344.93mm)
Figure 2-2. Panel Cutout Dimensions
9
