4117T Thin Line Industrial Flat Panel PC Chapter 2 – Installation

Wall Mounting

The 4117T is suitable for wall mount using the included brackets and hardware. See
Figure 2-5 for wall mounting bracket. See Figure 2-7, Figure 2-8 and Figure 2-9 for
wall-mounting diagrams
.
Figure 2-5. Wall Mounting Bracket
Figure 2-6. Chassis Support Screws
