4117T Light Duty Industrial PC
Options summary
Type
Select the type corresponding to the device present.
Not Installed : No device
Auto : Auto detected
CDROM: ATAPI CDROM
ARMD : ATAPI Removable Media Device
LBA/Large Mode
Disabled: Disables LBA Mode.
Auto: Enables LBA Mode if the device supports it and the device is not already formatted with
LBA Mode disabled.
Block (Multi-Sector
Transfer)
Disabled: The Data transfer from and to the device occurs one sector at a time.
Auto: The Data transfer from and to the device occurs multiple sectors at a time if the device
supports it.
PIO Mode
Chapter 3 – ICPMB-7570 CPU Board & BIOS Setup
Not Installed
Auto
Optimal Default, Failsafe Default
CDROM
ARMD
Disabled
Auto
Optimal Default, Failsafe Default
Disabled
Auto
Optimal Default, Failsafe Default
Auto
Optimal Default, Failsafe Default
0
1
2
3
4
35 144811(B)
