4117T Light Duty Industrial PC

Graphics Support

The graphics features listed below are all integrated on the 855GME chipset.

Display

Analog display support
Dual independent pipe support
DVO (DVOB and DVOC) support
Dedicated Local Flat Panel (LFP) LVDS interface

Internal Graphics Features

Core frequency
Intel® Embedded Graphics Drivers
Graphics interface support
Multi-monitor support
Dynamic display-mode support
Embedded video BIOS
o
Concurrent: different images and native display timings on each display
device
o
Simultaneous: same images and native display timings on each display
device
o
Digital video out ports DVOB and DVOC with 165 MHz dot clock on each 12-
bit interface; two 12-bit channels can be combined to form one dual-channel
24-bit interface with an effective dot clock of 330 MHz
o
Compliant with DVI Specification 1.0
o
Display core frequency of 133 MHz
o
Render core frequency of 133 MHz
o
GDI and DirectX* DirectDraw* with overlay for Windows* XP, Windows*
2000, and Windows* Embedded XP
o
XFree86*, XAA, and Xv for Linux*
o
Multiple programmable configurations
o
Dual independent display
o
DVO device support/TV-Out
o
User definable and extensible
o
Common port interface support
o
Full VGA compatibility
