Xycom 4117T User Manual page 76

4117T Light Duty Industrial PC
Error Messages
EISA CONFIGURATION
CHECKSUM ERROR
PLEASE RUN EISA
CONFIGURATION UTILITY
EISA CONFIGURATION IS NOT
COMPLETE
PLEASE RUN EISA
CONFIGURATION UTILITY
ERROR ENCOUNTERED
INITIALIZING HARD DRIVE
ERROR INITIALIZING HARD DISK
CONTROLLER
FLOPPY DISK CNTRLR ERROR
OR NO CNTRLR PRESENT
INVALID EISA CONFIGURATION
PLEASE RUN EISA
CONFIGURATION UTILITY
KEYBOARD ERROR OR NO
KEYBOARD PRESENT
KEYBOARD IS LOCKED OUT -
UNLOCK THE KEY
MEMORY ADDRESS ERROR AT
...
MEMORY PARITY ERROR AT ...
MEMORY SIZE HAS CHANGED
SINCE LAST BOOT
MEMORY VERIFY ERROR AT ...
OFFENDING ADDRESS NOT
FOUND
OFFENDING SEGMENT
PRESS A KEY TO REBOOT
PRESS F1 TO DISABLE NMI, F2
TO REBOOT
RAM PARITY ERROR -
CHECKING FOR SEGMENT
SHOULD BE EMPTY BUT EISA
BOARD FOUND
PLEASE RUN EISA
CONFIGURATION UTILITY
SHOULD HAVE EISA BOARD BUT
NOT FOUND
PLEASE RUN EISA
CONFIGURATION UTILITY
SLOT NOT EMPTY
Cause/Solution
The EISA non-volatile RAM checksum is incorrect or cannot correctly read the EISA
slot. This can indicate either the EISA non-volatile memory has become corrupt or the
slot has been configured incorrectly. Verify the card is installed firmly in the slot. When
this error appears, the system will boot in ISA mode allowing you to run the EISA
Configuration Utility.
The slot configuration information stored in the EISA non-volatile memory is
incomplete. When this error appears, the system will boot in ISA mode allowing you to
run the EISA Configuration Utility.
Check that the adapter is installed correctly and all cables are firmly attached. Verify
that the correct hard drive type is selected in Setup.
See the cord is correctly and firmly installed in the bus. Verify the correct hard drive
type is selected in Setup. Check jumper settings on the hard drive.
Make sure the controller is installed correctly and firmly. If there are no floppy drives
installed, be sure the Diskette Drive selection in Setup is set to NONE.
The non-volatile memory containing EISA configuration information was programmed
incorrectly or has become corrupt. The system will boot in ISA mode allowing you to
run the EISA Configuration Utility and correctly program the memory.
Make sure the keyboard is attached correctly and no keys are being pressed during
the boot. If you are purposely configuring the system without a keyboard, set the error
halt condition in Setup to HALT ON ALL, BUT KEYBOARD. This will cause the BIOS
to ignore the missing keyboard and continue the boot.
BIOS detected the keyboard is locked. P17 of keyboard controller is pulled low.
Indicates a memory address error at a specific location. You can use this location
along with the memory map for your system to find and replace the bad memory chips.
Indicates a memory parity error at a specific location. You can use this location along
with the memory map for your system to find and replace the bad memory chips.
Memory has been added or removed since the last boot. In EISA mode use
Configuration Utility to reconfigure the memory configuration. In ISA mode enter Setup
and enter the new memory size in the memory fields.
Indicates an error verifying a value already written to memory. Use the location along
with your system's memory map to locate the bad chip.
This message is used in conjunction with the I/O CHANNEL CHECK and RAM
PARITY ERROR messages when the segment that has caused the problem cannot be
isolated.
This message is used in conjunction with the I/O CHANNEL CHECK and RAM
PARITY ERROR messages when the segment that has caused the problem has been
isolated.
This will be displayed at the bottom screen when an error occurs that requires you to
reboot. Press any key to reboot.
When BIOS detects a Non-maskable Interrupt condition during boot, this will allow you
to disable the NMI and continue to boot, or you can reboot the system with the NMI
enabled.
Indicates a parity error in Random Access Memory.
A valid board ID was found in a slot that was configured as having no board
ID. When this error appears, the system will boot in ISA mode allowing you
to run the EISA Configuration Utility.
The board installed is not responding to the ID request, or no board ID has
been found in the indicated slot. When this error appears, the system will
boot in ISA mode allowing you to run the EISA Configuration Utility.
A slot designated as empty by the EISA Configuration Utility actually contains
a board. When this error appears, the system will boot in ISA mode allowing
you to run the EISA Configuration Utility.
72
Appendix B – Power-On Self-Test Messages
144811(B)
