Chapter 3 – ICPMB-7570 Motherboard

ICPMB-7570 CPU Board

Product Overview

The 4117T is equipped with a ICPMB-7570 Socket 479 Pentium M with CPU control
board. It is equipped with a high-performance processor and advanced high
performance multi-mode I/O.

Specifications

The following section lists some of the features of the 855GME and the ICH4
chipsets. For more information on these two chipsets please refer to the Intel website.
400 MHz system bus delivers a high-bandwidth connection between the processor
and the platform
Integrated graphics utilizing Intel® Extreme Graphics 2 technology
AGP 4X support
Three USB host controllers provide high-performance peripherals with 480 Mbps of
bandwidth, while enabling support for up to six USB 2.0 ports (only two available on
the I/O panel).
The latest AC '97 implementation delivers 20-bit audio for enhanced sound quality
and full surround sound capability
LAN Connect Interface (LCI) provides flexible network solutions such as 10/100 Mbps
Ethernet and 10/100 Mbps Ethernet with LAN manageability
Dual Ultra ATA/100 controllers, coupled with the Intel® Application Accelerator
support faster IDE transfers to storage devices
PCI Local Bus Specification, Revision 2.2-compliant with support for 33 MHz PCI
operations.
ACPI Power Management Logic Support
Enhanced DMA controller, Interrupt controller, and timer functions
Supports Audio Codec '97, Revision 2.3 specification
Alert On LAN* (AOL) and Alert On LAN 2* (AOL2)
14 144811(B)
