Xycom 4117T User Manual page 26

4117T Light Duty Industrial PC
FDD1 :FLOPPY CONNECTOR
PIN NO.
14 N/C
15 N/C
16 N/C
17 N/C
18 SA2
19 SA1
20 SA0
21 DATA 0
22 DATA 1
23 DATA 2
24 N/C
25 VCC-IN CHECK2
DESCRIPTION
1 GND
3 GND
5 NC
7 GND
9 GND
11 GND
13 GND
15 GND
17 GND
19 GND
21 GND
23 GND
25 GND
27 GND
29 GND
31 GND
33 GND
22
Chapter 3 – ICPMB-7570 CPU Board & BIOS Setup
39 CSEL
40 N/C
41 HDD_RESET
42 IORDY
43 SDREQ
44 SDACK#
45 HDD_ACTIVE#
46 66DET
47 DATA 8
48 DATA 9
49 DATA 10
50 GROUND
PIN NO. DESCRIPTION
2 DENSEL
4 NC
6 NC
8 INDEX
10 MTRA
12 DRVB
14 DRVA
16 MTRB
18 DIR
20 STEP
22 WDATA
24 WGATE
26 TRK0
28 WPT
30 RDATA
32 SIDE1
34 DSKCHG
144811(B)
