Table 35. Spanning Tree Variations Dell Networking OS Supports
Dell Networking Term
Spanning Tree Protocol (STP)
Rapid Spanning Tree Protocol (RSTP)
Multiple Spanning Tree Protocol (MSTP)
Per-VLAN Spanning Tree Plus (PVST+)

Implementation Information

• The Dell Networking OS implementation of PVST+ is based on IEEE Standard 802.1w.
• The Dell Networking OS implementation of PVST+ uses IEEE 802.1s costs as the default costs (as
shown in the following table). Other implementations use IEEE 802.1w costs as the default costs. If
you are using Dell Networking systems in a multivendor network, verify that the costs are values you
intended.

Configure Per-VLAN Spanning Tree Plus

Configuring PVST+ is a four-step process.
1. Configure interfaces for Layer 2.
2. Place the interfaces in VLANs.
3. Enable PVST+.
4. Optionally, for load balancing, select a nondefault bridge-priority for a VLAN.

Related Configuration Tasks

• Modifying Global PVST+ Parameters
• Modifying Interface PVST+ Parameters
• Configuring an EdgePort
• Flush MAC Addresses after a Topology Change
• Prevent Network Disruptions with BPDU Guard
• Enabling SNMP Traps for Root Elections and Topology Changes
• Configuring Spanning Trees as Hitless
• PVST+ in Multi-Vendor Networks
• Enabling PVST+ Extended System ID
• PVST+ Sample Configurations
636
IEEE Specification
802 .1d
802 .1w
802 .1s
Third Party
Per-VLAN Spanning Tree Plus (PVST+)
