This section provides information to help you:
Choose the correct consumables

Optimize cut quality

Pierce metal

Cut stainless steel with F5 gas


Choose the consumables

Your Duramax Lock machine torch ships with a starter consumable kit that contains a complete set
of shielded consumables plus 1 extra electrode and 1 extra nozzle. Consumables for gouging and
marking are available to order separately.
For details on gouging processes and consumables, see Gouge with the Hand Torch and

Machine Torch on page 71.
For details on the system's marking capabilities and consumables, see Guidelines for

Marking on page 113.
Consumables are shielded or unshielded.
Shielded consumables provide greater protection for the nozzle to minimize damage

caused from slag during piercing. Hypertherm recommends the use of shielded
consumables whenever possible.
If you are using unshielded consumables (for example, a deflector instead of a shield), be

careful to maintain the correct torch height in order to avoid damaging the nozzle from slag
or from accidental contact with the workpiece.
