Routine Maintenance

Every use

System
Check the indicator LED lights and correct
any fault conditions. See page 143.

Every consumable change or weekly (whichever is more frequent)

Test the torch-disable switch to make sure it
properly disables and activates the torch:
1. With the plasma power supply turned
ON, set the torch-disable switch to the
yellow lock (X) position.
2. Point the torch away from yourself and
others. Pull the trigger to make sure that
the torch does not fire an arc. For the
machine torch, run a START/STOP
command from the CNC.
3. Set the torch-disable switch to the
green "ready to fire" (
4. Point the torch away from yourself and
others. Pull the trigger 1 time. For the
machine torch, run a START/STOP
command from the CNC. Make sure
that the torch does not fire an arc. Make
sure that instead the torch emits
multiple puffs of air in quick succession.
See page 45.
Replace the torch-disable switch if it is not
working properly. See page 159.
152
Torch
) position.
Torch
Inspect the consumables for proper
installation and wear. See page 154.
