Page 1 ® Powermax45 Powermax45 XP Capacitor Replacement Kit Kit de remplacement du condensateur du Powermax45 Powermax45 XP Field Service Bulletin Bulletin de service sur le terrain 805950 – Revision 3 – December 2016 Révision 3 – Decembre 2016...
Page 2 (Technical Service Email) © 2016 Hypertherm, Inc. All rights reserved. Tous droits réservés. Powermax and Hypertherm are trademarks of Hypertherm Inc. and may be registered in the United States and/or other countries. All other trademarks are the property of their respective holders.
Page 3: Electric Shock Can Kill
This field service bulletin describes the steps necessary to replace the capacitors in the Powermax45. Powermax45 XP systems: Complete instructions for installing this kit are included in the Powermax45 XP Service Manual (809230). To download the manual, go to www.hypertherm.com/docs.
Page 4 6. Install the 2 new capacitors in their place, making sure their screw holes line up with the holes in the power board. IMPORTANT: Make sure the rubber vent holes on the capacitor tops are facing down, and line up with the vent holes in the power board. Powermax45/45 XP Field Service Bulletin 805950...
Page 5 8. Orient the fan plenum so the wider end is at the bottom, and snap the plenum into place. 9. Replace the component barrier that protects the power board. 10. Replace the power supply cover, and install the handle using the 2 screws removed earlier. Powermax45/45 XP Field Service Bulletin 805950...
Page 6 Powermax45/45 XP Capacitor Replacement Kit Powermax45/45 XP Field Service Bulletin 805950...
Page 7: Outils Et Matériel Requis
Ce bulletin de service sur le terrain décrit les étapes nécessaires pour le remplacement des condensateurs du Powermax45. Systèmes Powermax45 XP : Les instructions complètes pour l’installation de ce kit sont incluses dans le Manuel de service du Powermax45 XP (809230). Pour télécharger ce manuel, se rendre sur www.hypertherm.com/docs.
Page 8 6. Installer les deux nouveaux condensateurs à leur place, en s’assurant que les trous pour les vis sont alignés avec ceux du circuit imprimé d’alimentation. Powermax45/45 XP Bulletin de service sur le terrain 805950...
Page 9 9. Replacer la barrière de composant qui protège le circuit imprimé d’alimentation. 10. Remettre en place le couvercle de la source de courant et installer la poignée à l’aide des deux vis retirées auparavant. Powermax45/45 XP Bulletin de service sur le terrain 805950...
Page 10 Kit de remplacement du condensateur du Powermax45/45 XP Powermax45/45 XP Bulletin de service sur le terrain 805950...
