Installation and Setup

CCC 380 V (3-phase)

Input voltage
Input current at rated output (45 A x 145 V = 6.5 kW)
Input current at arc stretch
Recommended fuse/breaker size
Voltage tolerance

CE 400 V (3-phase)

Input voltage
Input current at rated output (45 A x 145 V = 6.5 kW)
Input current at arc stretch
Recommended fuse/breaker size
Voltage tolerance

CSA 480 V (3-phase)

Input voltage
Input current at rated output (45 A x 145 V = 6.5 kW)
Input current at arc stretch
Recommended fuse/breaker size
Voltage tolerance
30
380 V
12 A
20 – 15 A
20 A
+20% / -15%
400 V
11 A
20 – 15 A
20 A
+20% / -15%
480 V
9.4 A
17 – 12 A
20 A
+20% / -15%
