Weights

Hand torch with 6.1 m (20 foot) lead
Hand torch with 15 m (50 foot) lead

Choose the consumables

The 15° and 75° Duramax Lock hand torches use the same consumables.
Your system ships with a starter consumable kit that includes the shielded consumables on page 62
plus 1 extra electrode and 1 extra nozzle.
Consumable Type
Shielded drag-cutting
FineCut
®
HyAccess
TM
Maximum Control gouging (26 – 45 A)*
Precision gouging (10 – 25 A)*
Marking (10 – 25 A)
* For details on gouging processes and consumables, see Gouging processes on page 71.
For details on marking consumables, see Marking consumables (10 – 25 A) on page 113.
†
When you use the following
shielded and FineCut
consumables, select Cut mode
on the front panel. See page 51.
Powermax45 XP Operator Manual
Torch
Drag cut for the widest range of cutting applications.
Achieve narrower kerf on thin mild steel and stainless steel up to
3 mm (10 gauge).
Cut or gouge in hard to reach areas or confined spaces.
Remove metal and achieve a controlled gouge profile.
Achieve very shallow gouge and lower metal removal rate than
with Maximum Control gouging, such as for spot weld removal.
Mark metal surfaces using air or argon.
†
809240
Cut with the Hand Torch
Weight
1.8 kg (3.9 pounds)
3.7 kg (8.1 pounds)
Purpose
