Diagram 13
Diagram 13a
68
-To test for power coming in to the Fan control module, remove the 4 wire Molex from the fan
control module. Set meter to AC voltage, in a range of 200VAC and place one probe in the end
of each black wire. Reading should be approximately 120VAC. If no power confirm outlet is live.
MAXITROL GV60 IGNITION SYSTEM
TROUBLESHOOTING
Maxitrol GV60
