SUREFIRE ELECTRONIC IGNITION SYSTEM
S.I.T. PROFLAME 2 TROUBLESHOOTING
S.I.T. 886 VALVE DESCRIPTION
1. 6 Stage flame adjustment
2. Pilot adjustment
3. Inlet Pressure Tap
4. Outlet Pressure Tap
5. Pilot Outlet
6. Main Gas Outlet
7. Main Gas Inlet
4 3
2
1
PROFLAME 2 HANDHELD AND DISPLAY
5
6
SimTech Proflame II
Blue LCD display
7
ON/OFF display
THERMOSTAT Key
UP/DOWN Arrow Key
MODE Key
4 3
2
1
5
6
7
