SimTech ProFlame 1 Troubleshooting Manual page 20

Diagram 17
Check to ensure the receiver switch is set to the remote position (In center).
Set to Remote Position
(In Center)
Receiver Front Cover
Diagram 18
Check to ensure the remote handheld is turned on. The photo on the left shows Manual Mode on high. The photo on
the right shows Manual Mode on flame level 4.
20 20
SUREFIRE ELECTRONIC IGNITION SYSTEM
S.I.T. PROFLAME 1 TROUBLESHOOTING
Thermostat Display Off
Indicates
Manual Mode
Remote
Handheld
On/Off Button
Up/Down Arrow
Key for Burner or
Fan
Hole marked "PRG"
Coding Button
Receiver Switch
SimTech Proflame I
