SUREFIRE ELECTRONIC IGNITION SYSTEM
S.I.T. PROFLAME 1 TROUBLESHOOTING
Diagram 7 VOLTS DC TEST (VDC)
Check voltage at the green and white wires labeled ON/OFF. If a wall switch is used, check voltage at the switch.
(Switch must be in off position). The reading should be approximately 3 vdc. If no voltage proceed to the next step.
Check voltage at
wall switch. The
switch is in the off
position
Diagram 8 VOLTS DC TEST (VDC)
Check the voltage at the DFC. (Switch must be in the off position). The reading should be approximately 3 vdc.
If there is no voltage replace the DFC.
SimTech Proflame I
Check voltage at connections
