PLA is selected at "Material Right/Left."
· Overhang Threshold: When printing with support, enter a
number between 0˚ to 90˚ for the slicing engine to recognize
the support area. The degree values are measure from the
horizontal to the tangent line of the curve.
· Exterior Support Only (Available for Skeinforge): When this
option is checked, only exterior support will be built. For
example, when printing letter "O," supports will be considered
as interior support and when printing a letter "F," supports will
be consider exterior support.
· Restore Defaults: Reset all the changes to system default.
· Save Configuration: Save all the settings on this page. When slice
another object, it will load these saved settings.
L. View: Gives users 7 different directions to view the object.
· Show Model Outline: Displays an outline of all the objects.
· Show Steep Overhang: Displays steep overhang that possibly
needs support when printing.
M. Tools (
only available when Dreamer is connected to FlashPrint via USB
· Control Panel
· Homing
· Homing X: Move the extruder set to the right side until it
triggers the x-axis sensor and stop.
· Homing Y: Move the extruder to the back until it triggers the
y-axis sensor and stop.
· Homing Z: Move the build plate up until it triggers the z-axis
sensor and stop.
· Homing All: Perform homing for x, y, and z.
· Jog Mode
· Move the extruders and the platform to the direction of the
arrow buttons indicated. Pressing the button once will move
the extruders/platform by the increment selected at the drop-
down menu.
· Stop: When the extruders/platform is moving, this button will
stop this movement immediately.
