Page 2
1. Open the carton and take out lid of top of the 2. Take the power cable out. Remove two top foam printer. On the lid, there is one quick start, one sheets. after-sales service, one SD card, one leveling card and two build tapes.
Page 3
7. Open the paper box on the top of the printer, 8. Remove bubble bag outside the extruder, put there is an extruder, two side panels and an extruder on the extruder mounting base. extruder's accessory kit inside. Take the Notice: The extruder should be put as is shown extruder and the paper box out, notice that (extruder fan should towards the front of the...
Page 4
13. Take out filament first and then remove foam. 14. Notice: Do not miss either filament spool 15. Finally press build plate slowly to printer holder on two pieces of foam. bottom. 16. Dreamer unboxing completed. Suggest keeping packing materials well for follow-up storage and shipping.
Page 6
6.Platform Support 8.Thumb Screw 19.USB Cable Input...
Page 10
Install Filament 1. Take out the filament, remove vacuum packing and put it beside the left fixed seat of the build plate. For putting filament through guide tube easily, please install filament in a proper way. Left side Filament Filament Guide tube Guide tube Correct...
Page 11
Left side Right side 4. Take out filament spool holder. As is shown above, put spool holder through round hole, and insert it into fixed seat. Rotate the spool holder 90° to fix it. Attention: Lock filament on the left side, rotate spool holder anticlockwise 90° Lock filament on the right side, rotate spool holder clockwise 90°...
Page 12
Leveling 1. Take power cable out and plug it into power 2. Plug the other end of power cable into socket input on the right side of the printer. turn on the power switch. How to change language Password lock Disable Follow steps above if you need to do language setting.
Page 13
Berfore leveling, let's learn the funciton of thumb screw. How to use the thumb screw Build plate goes up Rotate thumb screw clockwise Build plate goes down Rotate thumb screw anticlockwise Please adjust the front thumb screw under Platform when stop. Filament Level Home...
Page 14
Attention: Leveling would affect print effect directly, if print result is unsatisfactory, please do leveling again. Start the adjustment process with the right nozzle, then use the distance between the right nozzle and build plate as a reference. 6. Take leveling card out, on the basis of right side extruder, put leveling card between right nozzle and build plate.
Filament Loading Filament Level Home Manual Print Preheat Setting Status About 1. Tap [Tools]. 2. Tap [Filament]. Load Left Unload Left L Extruder ℃ / 230℃ Load Right Cancel Unload Right 3. Tap [Load Left]. 4. Extruder starts to heat. Loading begins, push filament vertically into extruder, and press [Done] when you see filament come out of extruder...
6. Do not leave the printer unattended during side of the printer. operation. Print Preheat Tools 2. Tap [Print]. 3. Tap [SD card]. Dreamer User Guide 说明书 40mmCUBE-L-PLA FlashPrint 切片软件 40mmCUBE-R-PLA Happy3D Software软件安装包 Hillbert_Cube-PLA Test Files测试文件 4. Tap [Test Files].
Please follow steps below if you need to unload filament in Unloading Filament daily use. Filament Level Home Manual Print Preheat Setting Status About 1. Tap [Tools]. 2. Tap [Filament]. Load Left Unload Left L Extruder ℃ / 230℃ Load Right Cancel Unload Right 3.
Page 18
Withdraw Filament Press here 6. Then pull out vertically quickly and release spring presser. Tap [Finish], go back. Tap return arrow to go back to home screen.
