Page 1
EN/CN-A01 Guider 3 Plus 引领者 3 Plus 用户使用手册 USER GUIDE 中文P25 This guide is only applicable to FLASHFORGE Guider 3 Plus 3D printer 本手册仅适用于闪铸科技引领者 3 Plus打印机...
Page 4
Exposure to sunlight will accelerate the aging of plastic parts. Make sure to only use the power cord provided by Flashforge. Do not use the equipment during an thunderstorm. Please shut down the equipment and unplug it if it is not in use for a long time.
Page 5
The user has no right to make any modification to this user guide. Flashforge will not be responsible for any safety accidents caused by the disassembly or modification of the equipment by the customer. No one is allowed to modify or translate this guide without the permission of Flashforge.
1.2 Packing List 3D Printer Power Cord Lubricating Grease x 2 Glue Cleaning Brush Scraper Nipper Pliers Diagonal Pliers Straight Screwdriver Unclogging Pin Tool Allen Wrench Set Elbow Tweezers Leveling Card Heat Insulating Gloves 3D Printing Filament USB Flash Drive After-sales Service Card User Guide Fuse x 2...
2. Preparation Before Printing 2.1 Power Connection 1. Connect the power cord to the socket and equipment and press the switch to start the machine. 2. Turn on the screen switch and the screen light is on.
2.2 Filament Loading 1. Open the filament chamber, put in the filament and pass the filament through the corresponding filament sensor at the top of the chamber inside until the filament is visible from the other end of the filament guide tube; [Note: When printing, please put the filament in the left filament chamber for use.] Filament Handle...
Page 11
Load Unload Clean < Load Customize PETG PA66 PA12 PC-ABS PAHT PLA-CF PETG-CF < Load Customize Extruder heating, please insert the filament into the filament feeding roller as shown in the figure. 45/200℃ Cancel 3. Click the [ ] - [Load] on the screen, select the corresponding filament for the extruder, start filament feeding, and operate following the screen prompts.
2.3 Equipment Calibration The equipment includes the following leveling and calibration operations: Auto Level, Z Calibration The equipment has been leveled and calibrated before leaving the factory, so it is generally unnecessary to perform calibration again. However, the leveling plane may be damaged due to the vibration generated during transportation.
2.4 Network Connection 2.4.1 Wired Network Connection 1. Plug the network cable into the network cable port on the back of the equipment. 2. If the [ ] icon appears at the upper right corner of the screen, it indicates that the network is successfully connected.
4. First Printing 4.1 File Transfer: Wi-Fi Transfer Import the file to FlashPrint for slicing, select the machine type as Guider 3 Plus to connect to it [or by entering the IP address or by automatic scanning, while the IP address can be viewed in the [About] of the equipment].
After logging in, click the avatar icon at the upper right corner, click [Settings], and click the PIN Code in the menu to query the PIN code. After connecting Guider 3 Plus to the network, turn on the Polar Cloud switch and enter the account and PIN code.
4.4 Camera Connection 1. Please remove the camera cover before using the camera; 2. Turn on the camera switch; 3. After the equipment is connected to FlashPrint, the real-time video and image can be viewed in the FlashPrint - [Multi-Machine Control]. 4.5 Model Removal After Finishing Printing WARNING When removing the model from the build plate, please pay attention...
5. Equipment Operation Interface Introduction As the firmware will be upgraded from time to time, please ATTENTION refer to the actual display screens. The following is only a brief introduction of functions. 5.1 Printing Screen 220℃ 45℃ 2h 35m 15m/300g 0.18mm 1500 Print Queue...
5.2 Filament Screen < Load Customize PETG PA66 PA12 Load Unload Clean PC-ABS PAHT PLA-CF PETG-CF < Load Customize Please set the extruder temperature(℃): The filament screen includes: [Load], [Unload] and [Clean]. During filament loading and unloading, users can select the corresponding filament to be installed on the screen.
5.3 Preheating Screen The temperature of the extruder and platform can be set in advance as required on the preheating screen. Extruder Platform Extruder Platform 220℃ 45℃ 45℃/220℃ 45℃ Heating Heating Cancel Heating 5.4 Tools Screen Level and Home Manual Internet Cloud Calibration...
5.5 Settings Screen Settings Machine Name Guider 3 Plus Language English > Filament Sensor Platform Insulation 5min > Recover Printing Box Light On > Auto Shutdown Screen Brightness 85% > Air Filter On > Factory Reset > The several functions can be turned on or off on the settings screen.
6. Maintenance As the firmware will be upgraded from time to time, please ATTENTION refer to the actual display screens. The following is only a brief introduction of functions. 6.1 Maintenance Screen Users can click the [ ] - [Maintenance] to query the currently encountered problems. <...
At this time, the initial platform leveling is required. For this operation, users can contact Flashforge after-sales Special Note personnel for remote assistance with calibration.
Page 23
Position 1 3. Click the [ ]- [Manual] on the screen and click the Z-axis up arrow to manually move the extruder to Position 1 [above the leveling screw]; Stop when the Z-axis rises to the position where it is about to touch the nozzle; Insert the leveling card between the platform and nozzle and adjust the left M5*60 screw below the profile at the same time;...
7. Q&A Q1: How to deal with clogged nozzle? Click the [ ] - [Maintenance]. Q2: How to replace the nozzle? ATTENTION: Please disconnect the power before replacing the nozzle. Do not operate while energized. Click the [ ] - [Maintenance]. Q3: Is there a need to calibrate the extruder after replacing the nozzle? Q4: Click to start printing the model, and the extruder moves, but there is no filament extrusion at the beginning of printing.
Page 25
Q9: The printed model is warping or not sticking well. How to deal with this situation? Scheme 1: Increasing the platform temperature can effectively alleviate this problem, as the high temperature can increase the adhesion between the platform and the model. Scheme 2: Choosing to add a raft when slicing the model can effectively alleviate this problem.
Many of your problems can be solved in www.flashforge.com, the official English website of Flashforge. The Flashforge after-sales team can be reached by email or phone from 8:00 a.m. to 5:00 p.m. from Monday to Saturday to solve your problems. In case you contact us during off-duty time, your inquiry will be answered the following business day immediately.
