· Decreasing z value = moving object to the down
NOTE: Moving the object up or down (z-axis) may result in the object not being set on
the platform hence fail to print. Always make sure to put the object on the platform before
printing.
· On Platform: Brings the object to the platform and make sure it
prints successfully.
· Center: Brings the object to the middle of the platform.
· Reset: Reset all the position displacement changes have been
made to the object.
E. Rotate: Allows user to rotate the object respect to x, y, and z axis.
· Reset: Resets all the position changes that have been made to
the object.
F. Scale: Allows user to scale the object to a different size. You can
scale the object either by the actual dimension of the object or by
percentage.
· Uniform scaling: When this option is checked, changing one
of x, y and z axis values will change all three. This is to ensure
the shape of the object is not affected by changing its size.
(NOTE: Unchecking this box and changing one of the axis values will result in
changing the shape of the object)
· Maximum: Automatically scale the object to the maximum size
that the printer can print.
G. Cut: Left-click to select the target model, then click the [Cut] icon
and click again to enter the settings screen, in which users can set the
direction and the position. You can cut with your mouse or according to
the X, Y or Z axis. On top of this, you can enter an exact value to set a
specific position.
H. Extruder: Allow users to choose which extruder they would like to
print the object. Object that print with either extruders would
show in the corresponding color.
I. File:
