Technical Information

Configuration

GetParameter

GetParameterResponse

SetParameter

PVED-CL Communication Protocol, version 1.38 Technical Information
This message is used to retrieve a value of a given parameter. If an unknown parameter value is
requested, no response will be sent back. Timeout policy shall be applied.
CAN message
Priority
PGN
XID
Occurrence
Modes
Sent by
Sent to
Data field
Bytes Encoding
1, 2 UNSIGNED16
3, 4 UNSIGNED16
This message is sent upon the GetParameter request and contains both parameter index and parameter
value.
CAN message
Priority
PGN
XID
Occurrence
Modes
Sent by
Sent to
Data field
Bytes Encoding
1, 2 UNSIGNED16
3, 4 UNSIGNED16
5 – 8 UNSIGNED32
This message is used to set value of a given parameter. Please note that the values are not stored in non-
volatile memory unless CommitData command is sent.
11079551 • Rev BA • July 2014
6
61184
0x0FA0 (MSB first)
when required
operational, reduced, calibration and fault
configuration tool, high priority external set-point controller
PVED-CL
Value/Range Description
0x0FA0 (MSB first) extended message identifier (XID)
(see parameter list) parameter index
6
61184
0x0FA1 (MSB first)
upon request
operational, reduced, calibration and fault
PVED-CL
configuration tool or high priority external set-point controller
Value/Range Description
0x0FA1 (MSB first) extended message identifier (XID)
(see parameter list) parameter index
(depends on a parameter value
parameter)
17
